Product Description:

The MKD112C-024-GP0-AN is a servo motor built by Bosch Rexroth Indramat within the MKD Synchronous Motors series. As a rotary actuator, it pairs with digital drive controllers to deliver precise speed, position, and torque control on automated production equipment. By converting controlled three-phase energy into mechanical rotation and returning feedback to the drive, the unit supports coordinated motion on packaging machines, gantry axes, and machining centers where accurate positioning under varying load is required. The motor belongs to an AC synchronous product line intended for fast response during cyclic-duty operation, including applications with frequent starts, stops, and direction changes.

A centering collar of 130 mm provides concentric alignment to the machine flange, which follows a square pattern with a 192 mm bolt circle. At zero speed, the motor can sustain a continuous load of 38.0 Nm, which supports steady holding torque during static machine operation. Rotor position is measured by resolver feedback (RSF), which sends analog sine-cosine signals to the drive for commutation and position tracking. Because the unit is supplied without a holding brake, any power-off locking must be provided by external equipment. All power and feedback conductors exit on Side A, so the connection direction remains fixed for cable routing and strain relief.

The motor has size 112 and a stack length coded as C, which indicate its frame proportions and installation envelope. Stator windings follow code 024, allowing the matched drive to provide the appropriate current and voltage characteristics. Output torque is transmitted through a shaft with keyway, and the shaft seal helps reduce the entry of lubricant and contaminants at the output end. The motor uses an output connector for cable attachment, and the resolver supplies relative position information to the controller during operation.
