Product Description:

The MKD112C-024-GG3-LN is a servo motor manufactured by Bosch Rexroth Indramat within the MKD Synchronous Motors series. In automated machinery, this motor converts drive controller commands into rotational motion for precise axis positioning in packaging lines, transfer systems, and material-handling stations. Its permanent-magnet synchronous construction supports rapid acceleration, while the integrated feedback device closes the loop for stable speed regulation during repeated start-stop cycles. It is commonly applied on servo axes that require repeatable motion under changing loads. This model is suited to applications that balance moderate frame dimensions with the need for high continuous torque in round-the-clock production cells.

At stall it can deliver a continuous torque of 38.0 Nm, enabling steady support of cutting or forming forces while the rotor remains locked. The mounting flange measures 192 mm, and a centering pilot of 130 mm keeps the shaft concentric with driven loads. An integrated brake supplies 70 Nm of holding torque to secure vertical axes when power is removed. Rotor position is measured by a resolver feedback (RSF) device, which tolerates high electrical noise and returns rotor angle data to the drive for current vector control.

All electrical power is routed through a power connector positioned on the left, simplifying cable runs in cabinets with fixed trunking. The mechanical output uses a plain shaft protected by a lip seal that helps prevent coolant or dust from entering the front bearing. Winding code 024 indicates resistance and inductance values that match the drive family's nominal current range. The sealed housing helps limit contamination when the motor is installed on machinery exposed to coolant spray, and the fixed connector orientation supports consistent harness routing across multiple axes. This layout is useful on machines where cable paths must stay clear of moving guards, linear slides, or nearby process hardware.
