MKD112C-024-GG3-AN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911283246
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112C-024-GG3-AN is a servo motor from the MKD Synchronous Motors series and features a 130 mm centering diameter and 192 mm flange size. The motor uses resolver feedback (RSF) for position detection and provides a continuous standstill torque of 38 Nm. It comes with a holding brake rated at 70 Nm and has a plain shaft with a shaft seal.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112C-024-GG3-AN servo motor is built by Bosch Rexroth Indramat within the MKD Synchronous Motors series. It serves as an electromechanical actuator that transforms drive-supplied three-phase power into regulated rotary motion for indexing tables, pick-and-place axes, and other automated equipment. When paired with a compatible digital drive controller, the motor supports closed-loop speed and position regulation for repeatable motion during automatic cycles. This operating arrangement is well suited to machinery that needs accurate starts, controlled stops, and stable dwell periods while handling changing loads throughout production.
Its continuous standstill torque is 38.0 Nm, permitting stable force delivery when the axis is motionless yet energized. A built-in holding brake secures loads during power-off events and provides up to 70 Nm of static holding torque, which helps keep loads from drifting when motion is not commanded. Rotor position is monitored through resolver feedback, providing analog sine-cosine signals suited for rugged environments while supporting the drive’s relative position detection mode. For mechanical integration, the housing has a 192 mm square mounting flange and a 130 mm centering diameter, which help align the motor accurately on machine frames and maintain shaft concentricity with the driven components.
All electrical terminations are routed on side A, which can simplify cable routing where installation depth is limited or where one-sided cable entry is preferred. A factory-installed shaft seal protects the front bearing against coolant splash and airborne contaminants, helping support IP65 protection when sealed connectors are used. The internal copper uses winding code 024, which matches the motor with drives that can supply the required voltage and current for its thermal behavior under load. Power is transmitted through a plain shaft, eliminating keyways and reducing stress concentrations on couplings, while the size 112 frame with length code C keeps the motor suitable for medium-inertia motion axes.
Frequently Asked Questions about MKD112C-024-GG3-AN:
Q: What is the continuous torque at standstill for the MKD112C-024-GG3-AN motor?
A: The MKD112C-024-GG3-AN motor features a continuous torque of 38.0 Nm at standstill.
Q: Does the MKD112C-024-GG3-AN include a holding brake and what is the brake torque?
A: This model is equipped with a holding brake providing a holding brake torque of 70 Nm.
Q: What type of position detection does the MKD112C-024-GG3-AN use?
A: Position detection on this unit uses resolver feedback (RSF) and operates on a relative basis.
Q: What is the shaft design and does the MKD112C-024-GG3-AN include a shaft seal?
A: The MKD112C-024-GG3-AN motor includes a shaft seal and features a plain shaft design for secure coupling.
Q: In which direction is the electrical connection made on the MKD112C-024-GG3-AN motor?
A: The connection is directed to Side A and uses an output connector for interfacing.
