MKD112C-024-GG0-LN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911291501
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112C-024-GG0-LN is a servo motor that is part of the MKD Synchronous Motors series. It features a continuous torque at standstill of 38.0 Nm and a plain shaft design with a shaft seal. The motor has a resolver feedback encoder, an insulation class F, and is protected with an IP65 category.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112C-024-GG0-LN is a servo motor built by Bosch Rexroth Indramat for the MKD Synchronous Motors series. It supplies closed-loop rotary motion for automated axes, enabling coordinated positioning, indexing, and speed control wherever compact electric drives are required in industrial automation. The unit interfaces with digital drive controllers that modulate three-phase supply current to match changing load demands. It is suitable for machine axes that need repeatable motion in handling, transfer, and general production equipment.
Its continuous torque at standstill is 38.0 Nm, so the shaft can support static process loads without a mechanical holding brake in some applications. The enclosure meets IP65, which helps keep dust and low-pressure water jets away from internal components. Rated service is maintained in ambient temperatures from 0 to 40 °C, a range that fits typical industrial operating conditions. Accurate mechanical alignment is provided by a 130 mm centering diameter that matches the mounting pilot. Rotor position is captured through resolver feedback (RSF), supplying sinusoidal reference signals to the drive for commutation and velocity control. The power connector is located on the left side of the housing, which helps simplify cable routing in multi-axis machines. A plain shaft with a factory-installed shaft seal transmits torque while helping protect the front bearing area from contamination.
The square flange measures 192 mm, and together with motor size 112 and length code C, it sets the mounting envelope for compatible machine interfaces. Windings built to insulation class F tolerate elevated copper temperatures during peak duty. The electromagnetic set coded 024 sets the resistance and inductance values used with matching MKD drives. Position repeatability is held within ±8 angular minutes, which supports general-purpose servo tasks when relative position detection is sufficient. Because the motor is supplied without a holding brake, vertical axes require an external holding method when power is removed. The shaft arrangement is intended for direct coupling to gearboxes or pulleys in clean but demanding machine areas.
Frequently Asked Questions about MKD112C-024-GG0-LN:
Q: What is the continuous torque at standstill for the MKD112C-024-GG0-LN?
A: The MKD112C-024-GG0-LN servo motor offers a continuous torque of 38.0 Nm when at standstill.
Q: Which encoder type is integrated in the MKD112C-024-GG0-LN model?
A: Resolver feedback (RSF) is used for position detection on this motor.
Q: What type of shaft does the MKD112C-024-GG0-LN utilize?
A: A plain shaft design is featured on the MKD112C-024-GG0-LN servo motor.
Q: Does the MKD112C-024-GG0-LN include a holding brake?
A: This model comes without a holding brake.
Q: What protection category does the MKD112C-024-GG0-LN motor offer?
A: The MKD112C-024-GG0-LN motor provides IP65 protection, ensuring it is highly resistant to dust and water ingress.
