MKD112C-024-GG0-AN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911277858
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112C-024-GG0-AN is a servo motor from the MKD Synchronous Motors series. It features a 192 mm flange size and a centering diameter of 130 mm, with a plain shaft design that includes a shaft seal. This servo motor provides a continuous torque of 38.0 Nm at standstill and uses resolver feedback for position detection.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112C-024-GG0-AN is a servo motor produced by Bosch Rexroth Indramat for the MKD Synchronous Motors series. It is intended for closed-loop industrial automation where precise torque control and repeatable motion are required. By combining an AC synchronous design with resolver feedback, the motor works with a compatible drive controller to maintain commanded velocity and position. Its feedback and synchronous operation help the drive correct speed error quickly during indexing and contouring moves.
A continuous standstill torque of 38.0 Nm allows the motor to support load at zero speed without active cooling. The centering diameter of 130 mm helps align the motor with gearboxes or machine plates, and the square flange spans 192 mm for mounting on common machine faces. Power and feedback conductors leave the housing on side A and connect through an output connector, which keeps the electrical interface compact. Motion feedback uses resolver feedback (RSF), providing analog angle signals that remain reliable in electrically noisy areas and at elevated operating temperatures. The connector layout also simplifies cable routing where space near the motor body is limited.
A plain shaft supports coupling to clamping hubs, and a shaft seal helps protect the bearing area from fine dust and lubricants. Frame size 112 places the motor in a mid-frame format, while the C motor length offers a balanced relationship between torque capacity and rotor inertia. Winding code 024 sets the electrical characteristics expected by the matching drive, including the current response needed for controlled acceleration and deceleration. The motor is supplied without a holding brake, so parked loads must be secured by external mechanics or by controlled drive torque after startup reference routines are completed.
Frequently Asked Questions about MKD112C-024-GG0-AN:
Q: What type of encoder is used on the MKD112C-024-GG0-AN servo motor?
A: The MKD112C-024-GG0-AN features resolver feedback (RSF) for position detection.
Q: What is the continuous torque at standstill for the MKD112C-024-GG0-AN?
A: This motor provides a continuous standstill torque output of 38.0 Nm.
Q: What shaft configuration is available on the MKD112C-024-GG0-AN motor?
A: The MKD112C-024-GG0-AN is built with a plain shaft and comes equipped with a shaft seal for added protection.
Q: Does the MKD112C-024-GG0-AN include a holding brake?
A: The MKD112C-024-GG0-AN is designed without a holding brake.
Q: What is the connection direction and type for the MKD112C-024-GG0-AN motor?
A: The electric connection on this model is made through an output connector on Side A.
