MKD112B-048-KP0-LN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911277803
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112B-048-KP0-LN is a servo motor from the MKD Synchronous Motors series. It features a continuous torque at standstill of 28.0 Nm, IP65 protection, and a centering diameter of 130 mm. This motor is equipped with resolver feedback with integrated encoder for absolute position detection greater than 4096 revolutions and has a shaft with keyway and shaft seal.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112B-048-KP0-LN is a servo motor manufactured by Bosch Rexroth Indramat and supplied within the MKD Synchronous Motors series. In automated machinery, the unit converts controlled three-phase energy from a drive into regulated rotary motion, making it suitable for positioning tables, packaging axes, and material-handling modules that require repeatable speed and torque. The motor is shipped as a stand-alone electromechanical actuator that integrates rotary feedback and sealing features to simplify installation inside production equipment.
At standstill, the motor can deliver a continuous torque of 28.0 Nm, allowing it to hold or move loads without overheating when the shaft is locked by the drive. Rotor angle is reported through resolver feedback, which supplies absolute information over more than 4096 revolutions. System repeatability is within ±8 angular minutes, supporting consistent registration in pick-and-place routines. Mechanical centering during mounting is guided by a 130 mm pilot diameter on the front flange, while overall ingress protection reaches IP65 so dust and low-pressure water jets cannot reach the stator windings. The left-side orientation of the power connector simplifies cable routing in cabinets where all MKD112 frames use the same B-length housing, size-112 stator stack, and 048 winding code. Because the motor is supplied without a holding brake, holding torque must be provided by the drive or an external clamp when power is removed.
The square flange measures 192 mm across, providing a standardized bolt pattern that matches gearboxes and planetary reducers used on mid-frame robots. Thermal limits are aligned with a permissible ambient range of 0–40 °C, and within this window the Class F insulation system keeps winding temperature below its 155 °C ceiling. The output shaft is a shaft with keyway and includes an integral shaft seal that transmits torque while blocking lubricants from entering the bearing space. The screened power connector and separate resolver harness use quick-lock fittings, which keep both connections secure during operation.
Frequently Asked Questions about MKD112B-048-KP0-LN:
Q: What is the continuous torque at standstill for the MKD112B-048-KP0-LN motor?
A: The MKD112B-048-KP0-LN provides a continuous torque of 28.0 Nm at standstill.
Q: What type of encoder is used on the MKD112B-048-KP0-LN motor?
A: This model offers resolver feedback with an integrated encoder for feedback signals.
Q: Does the MKD112B-048-KP0-LN include a holding brake?
A: The MKD112B-048-KP0-LN is manufactured without a holding brake.
Q: What level of protection does the MKD112B-048-KP0-LN motor have?
A: The protection rating for this motor is IP65, ensuring resistance to dust and low-pressure water jets.
Q: How does the MKD112B-048-KP0-LN handle position detection?
A: Position detection is absolute and supports more than 4096 revolutions on this model.
