MKD112B-048-GP0-AN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911273857
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112B-048-GP0-AN is a servo motor from the MKD Synchronous Motors series with a centering diameter of 130 mm and flange size of 192 mm. It features a continuous torque of 28.0 Nm at standstill, a shaft with keyway, and resolver feedback for position detection. This model has a side A output connector and does not include a holding brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112B-048-GP0-AN servo motor is built by Bosch Rexroth Indramat within the MKD Synchronous Motors series. Intended for use in CNC machines, packaging lines, and material-handling axes, the unit converts commanded drive current into controlled rotary motion. It supports closed-loop operation in which the drive continuously adjusts torque and speed to follow programmed motion with repeatable accuracy. Its synchronous design also helps the amplifier maintain smooth movement during contouring tasks and coordinated multi-axis cycles.
At standstill, it delivers a continuous torque of 28.0 Nm, allowing the axis to hold substantial loads without excessive thermal buildup. The locating shoulder measures 130 mm, which helps center the motor accurately against the mating surface, and the square flange spans 192 mm for direct mounting to common machine interfaces. This arrangement supports rigid installation and helps keep alignment error low during assembly. Cables exit on Side A, which can simplify routing when several axes share the same cabinet or machine wall. The motor uses an output connector so power connections are made through a compact, enclosed interface.
The motor integrates resolver feedback, so the drive receives analog sine-cosine signals for speed evaluation and position tracking relative to the electrical zero point. That feedback method is well suited to industrial environments where reliable signal transmission is important during continuous motion. Winding code 048 identifies the stator coil data used by the matching drive for current regulation. A shaft with keyway provides a positive drive connection for pulleys or couplings, and the shaft seal helps limit the entry of dust or coolant splash. The unit is supplied without a holding brake, so any required load retention during power loss must come from an external device or commanded motor torque. Frame size 112 with length code B gives the motor a moderate inertia level for medium-duty axes that need a balance between responsiveness and continuous load capacity.
Frequently Asked Questions about MKD112B-048-GP0-AN:
Q: What type of feedback does the MKD112B-048-GP0-AN motor provide for position detection?
A: The MKD112B-048-GP0-AN uses resolver feedback (RSF) for position detection, which provides relative position information.
Q: What is the continuous torque at standstill for the MKD112B-048-GP0-AN?
A: This model supplies a continuous torque of 28.0 Nm at standstill.
Q: Does the MKD112B-048-GP0-AN include a holding brake?
A: The MKD112B-048-GP0-AN is manufactured without a holding brake.
Q: What is the shaft design of the MKD112B-048-GP0-AN motor?
A: This servo motor features a shaft with keyway and is equipped with a shaft seal.
Q: What connection configuration does the MKD112B-048-GP0-AN have?
A: The electrical connection on this model is oriented toward Side A and uses an output connector.
