MKD112B-024-KP1-LN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911307952
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112B-024-KP1-LN is a servo motor from the MKD Synchronous Motors series. It features a flange size of 192 mm, centering diameter of 130 mm, and is equipped with a shaft with keyway and shaft seal. The motor provides 28 Nm continuous torque at standstill and 22 Nm holding brake torque, and includes resolver feedback with integrated encoder for absolute position detection over 4096 revolutions.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112B-024-KP1-LN is a servo motor produced by Bosch Rexroth Indramat within the MKD Synchronous Motors series. It is intended for closed-loop positioning and speed control in automated machinery, where synchronous operation with a drive controller delivers precise torque and repeatable motion profiles for tooling, handling, or packaging axes. This type of motor is commonly paired with a servo drive that regulates current and speed in real time to keep axis motion consistent under changing loads. The B-length frame provides a balance between torque density and overall motor depth for mid-range duty cycles.
At standstill, the motor can exert 28.0 Nm continuously, which indicates the continuous torque available while the shaft is held by the drive. The mechanical interface uses a centering diameter of 130 mm and a square flange that measures 192 mm, allowing the motor to fit standardized mounting patterns. The square flange and centering shoulder help align the motor to machine plates or gearboxes without extra adapter parts. Connections exit on the left side, so the installation must allow room for cable routing, and power is transferred through a power connector that mates with the corresponding drive cable. Winding code 024 corresponds to the stator wire gauge and turns count used for this motor.
An integral holding brake supplies 22 Nm of static torque to maintain load position during power loss or emergency stops. This is useful on axes that must remain in place when electrical power is removed. Rotor position is detected by resolver feedback, which sends analog sine-cosine signals to the controller, while the integrated electronics provide absolute feedback with more than 4096 revolutions so homing is not required after shutdowns. Output is delivered through a shaft with a keyway, which provides positive mechanical engagement for pulleys or couplings, and a shaft seal helps block coolant spray and fine dust.
Frequently Asked Questions about MKD112B-024-KP1-LN:
Q: What is the continuous torque at standstill for the MKD112B-024-KP1-LN?
A: This servo motor provides a continuous torque of 28.0 Nm at standstill.
Q: Does the MKD112B-024-KP1-LN include a holding brake?
A: Yes, the MKD112B-024-KP1-LN is equipped with a holding brake.
Q: What type of encoder does the MKD112B-024-KP1-LN servo motor use?
A: Resolver feedback with an integrated encoder is used for position detection on this model.
Q: What shaft design is provided on the MKD112B-024-KP1-LN?
A: The shaft of this motor features a keyway and comes with a shaft seal.
Q: What is the connection direction for the power connector on the MKD112B-024-KP1-LN?
A: The power connection on this model is configured to the left side of the motor.
