MKD112B-024-KP1-BN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911273435
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112B-024-KP1-BN is a servo motor from the MKD Synchronous Motors series and features a centering diameter of 130 mm with a flange size of 192 mm. It is equipped with resolver feedback with integrated encoder for absolute position detection greater than 4096 revolutions. The servo motor has a continuous torque at standstill of 28.0 Nm and a holding brake torque of 22 Nm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112B-024-KP1-BN synchronous motor is built by Bosch Rexroth Indramat as part of the MKD Synchronous Motors series. Designed for industrial automation, the unit couples to digital drive controllers to translate commanded current into precise shaft rotation for indexing, conveying, or tool positioning. Its B-length housing and 112 frame size balance thermal capacity with footprint, while integrated feedback supports vector-controlled operation so production equipment maintains programmed velocities and repeatable positioning across long duty cycles. It is commonly integrated into pick-and-place cells, servo presses, and gantry axes.
The motor supplies a continuous standstill torque of 28.0 Nm, allowing axes to hold load without overheating when stationary. Mounting is handled through a square flange that measures 192 mm, and correct concentricity is maintained by a 130 mm centering diameter that fits standard precision machine frames. Power and feedback cabling exit on Side B through an Output connector, simplifying service because the plug can be uncoupled without disassembling the housing. Electromagnetic behavior is defined by the stator’s 024 winding code, matching resistance and inductance to medium-voltage drives for efficient current utilization.
A permanent-magnet holding brake develops 22 Nm of torque so vertical or suspended loads remain secure when the drive is disabled. Rotor position is monitored by Resolver feedback, and because the resolver is paired with electronic counting logic, the system delivers Absolute position (>4096 revs) data for instant reference after power restoration. Mechanical power is transmitted through a Shaft with keyway; the keyed interface prevents slip during bidirectional torque cycles, and an integral shaft seal blocks lubricant migration toward the bearing journals, supporting long service intervals despite frequent speed changes.
Frequently Asked Questions about MKD112B-024-KP1-BN:
Q: What is the continuous torque at standstill for the MKD112B-024-KP1-BN motor?
A: The MKD112B-024-KP1-BN provides continuous torque at standstill of 28.0 Nm for demanding servo applications.
Q: What type of position detection does the MKD112B-024-KP1-BN servo motor provide?
A: This motor offers position detection with absolute feedback for more than 4096 revolutions, utilizing its integrated resolver encoder.
Q: What is the shaft design of the MKD112B-024-KP1-BN motor?
A: The shaft on this model features a keyway and is supplied with a shaft seal for added protection against contaminants.
Q: What is the holding brake torque of the MKD112B-024-KP1-BN?
A: The holding brake torque for this servo motor is rated at 22 Nm, assisting with secure load holding when powered off.
Q: Where is the electrical connection located on the MKD112B-024-KP1-BN servo motor?
A: The electrical connection for this model is provided via an output connector located on side B of the motor.
