MKD112B-024-GP1-BN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911277242
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112B-024-GP1-BN is a servo motor from the MKD Synchronous Motors series, featuring a motor size of 112 and a centering diameter of 130 mm. It provides a continuous torque at standstill of 28.0 Nm and includes a holding brake with a torque of 22 Nm. The motor is equipped with resolver feedback for position detection and features a shaft with keyway and shaft seal.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112B-024-GP1-BN is a servo motor produced by Bosch Rexroth Indramat within the MKD Synchronous Motors series. It converts controlled electrical power from a drive into rotary motion for positioning, indexing, and continuous-duty tasks on automated lines and material-handling equipment. Its synchronous design supports repeatable torque and speed during demanding production cycles, making it suitable for coordinated motion where acceleration, stopping accuracy, and steady running all matter.
At standstill, the motor can deliver a continuous torque of 28.0 Nm, allowing it to hold or inch sizable loads without exceeding its thermal limit. The flange has a centering recess of 130 mm, which helps align the motor accurately to reducers or timing-belt pulleys. Power and feedback leads exit from Side B of the housing, which can simplify cable routing when the shaft faces the operator. The 024 winding code indicates the electrical winding configuration used for this motor variant, which affects the voltage and current relationship expected by the matching drive. A built-in holding brake provides 22 Nm of static torque to keep vertical or suspended axes in place during power loss or an emergency stop. A shaft seal also helps keep coolant or oil from traveling along the shaft. The motor uses relative position detection, so the axis requires a homing move after startup.
The motor size of 112 gives the unit a mechanical envelope suited for mid-range presses, gantry axes, and packaging spindles where stable servo response is needed under changing load. Rotor position is reported through Resolver feedback (RSF), which tolerates vibration and temperature variation while supplying analog sine-cosine signals to the servo drive. Power is connected through an output connector mounted at the rear, and torque is transmitted through a shaft with keyway for positive engagement during frequent reversals. Motor length B keeps the overall depth relatively compact for this frame and helps the motor fit installations with limited mounting space.
Frequently Asked Questions about MKD112B-024-GP1-BN:
Q: What is the continuous standstill torque of the MKD112B-024-GP1-BN motor?
A: The MKD112B-024-GP1-BN delivers a continuous torque at standstill of 28.0 Nm.
Q: What type of shaft configuration is provided on the MKD112B-024-GP1-BN?
A: This motor uses a shaft with keyway and includes a shaft seal for added protection.
Q: What encoder type is used for position feedback in the MKD112B-024-GP1-BN?
A: The encoder type on this model is resolver feedback (RSF), supporting relative position detection.
Q: Does the MKD112B-024-GP1-BN come with a holding brake?
A: A holding brake is included on this motor and delivers a brake torque of 22 Nm.
Q: What is the connection type and direction for the MKD112B-024-GP1-BN servo motor?
A: The electrical connection is an output connector oriented on Side B of the unit.
