MKD112B-024-GG1-BN Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911274569
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MKD112B-024-GG1-BN is a servo motor from the MKD Synchronous Motors series. It features a 192 mm flange size, a centering diameter of 130 mm, and a plain shaft with a shaft seal. The motor provides 28.0 Nm of continuous torque at standstill and includes a holding brake with 22 Nm of torque.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MKD112B-024-GG1-BN is a servo motor manufactured by Bosch Rexroth Indramat in the MKD Synchronous Motors series. In automated machinery, the motor interfaces with a digital drive controller to deliver closed-loop rotary motion for indexing tables, packaging axes, and material-handling gantries that require repeatable speed and position control during continuous production. Position detection is relative, so an electronic homing sequence is required after each power cycle.
At a standstill the unit produces a continuous torque of 28.0 Nm, so the axis can hold process loads without overheating during dwell periods. A flange dimension of 192 mm matches the motor Size 112 housing and seats against standard IEC machine frames, while the centering diameter of 130 mm aligns the stator concentrically to reduce radial runout at the machine interface. Power and feedback leave the housing on Side B through an output connector, simplifying cable routing in multi-axis cabinets and keeping connections grouped on one side of the motor. Motion feedback is generated by resolver feedback (RSF), which provides analog sine-cosine signals for high-resolution interpolation by the controller. The motor uses winding code 024, which corresponds to the coil resistance and inductance combination selected for moderate base speeds with compatible inverters.
An integrated holding brake develops 22 Nm of static torque to secure vertical or overhung loads when power is removed. The mechanical interface uses a plain shaft without a keyway, enabling direct clamp coupling and minimizing backlash in the connection to the driven load. A shaft seal protects the bearings from coolant splash, airborne dust, and other common contaminants found around machinery. Motor length code B balances rotor inertia against the Size 112 laminations to support rapid acceleration profiles while keeping the overall housing length moderate for compact machine layouts.
Frequently Asked Questions about MKD112B-024-GG1-BN:
Q: What encoder type is used for position detection on the MKD112B-024-GG1-BN motor?
A: This model features resolver feedback (RSF) for position detection, which offers relative positioning capability.
Q: Does the MKD112B-024-GG1-BN have a holding brake and what is its brake torque?
A: A holding brake with a torque of 22 Nm is included on this servo motor.
Q: What is the continuous torque at standstill of the MKD112B-024-GG1-BN motor?
A: The continuous torque at standstill for the MKD112B-024-GG1-BN is rated at 28.0 Nm.
Q: What is the shaft design and does it include a seal on the MKD112B-024-GG1-BN motor?
A: The shaft features a plain design and includes a shaft seal for added protection.
Q: Where is the electrical connection positioned on the MKD112B-024-GG1-BN, and what type of connector does it use?
A: The electrical connection is configured on Side B of the motor using an output connector.
