Product Description:

The MKD071B-061-KG0-KN belongs to the MKD Synchronous Motors series from Bosch Rexroth Indramat. It is a permanent-magnet AC servo motor intended for closed-loop industrial drive systems where position and velocity must follow controller commands with consistent response. By coupling directly to gearboxes, ball screws, or belt transmissions, the motor converts electrical energy from the drive into mechanical rotation for packaging lines, pick-and-place axes, and material-handling gantries. Its synchronous design supports repeatable torque production during frequent starts, stops, and speed changes in automated machinery.

This model produces a continuous standstill torque of 8.0 Nm, enabling it to hold loads during extended dwell periods without overheating. Mechanical alignment to mating machine frames is supported by a centering diameter of 95 mm and a square mounting interface that uses a 115 mm flange. The electromagnetic circuit uses winding code 061, which sets the phase resistance and inductance so the matched drive can deliver rated current without saturation. Rotor position is reported by resolver feedback, supplying analog sine-cosine signals for commutation during rapid acceleration and changing load conditions.

Cabling exits from Side B, and the power and feedback conductors terminate inside a sealed connection box that helps protect the wiring interface. Rear cable exit can simplify routing where the motor is mounted close to a gearbox or machine plate. The output shaft is a plain shaft, so couplings or pulleys can be mounted with friction hubs or clamp elements instead of keyed joints. The feedback system tracks absolute position over more than 4096 revs, allowing the axis to recover its mechanical reference after power cycles without homing moves. This layout supports repeatable startup behavior in coordinated multi-axis equipment.
