MHP112C-058-HG0-ANNNNN

  • Rated 4.5 (21 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911289220
  • Call for Expedited Shipping and Product Condition Options
MHP112C-058-HG0-ANNNNN Servo Motor is manufactured by Rexroth, Indramat, Bosch. This motor has a Plain Shaft with Sealing Ring shaft and windings of 58. This motor is also Not Equipped with a holding brake and has an Incremental encoder.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

MHP112C-058-HG0-ANNNNN

  • Rated 4.5 (21 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911289220
  • Call for Expedited Shipping and Product Condition Options
MHP112C-058-HG0-ANNNNN Servo Motor is manufactured by Rexroth, Indramat, Bosch. This motor has a Plain Shaft with Sealing Ring shaft and windings of 58. This motor is also Not Equipped with a holding brake and has an Incremental encoder.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Repairs
Sell Us Your Surplus
Have a MHP112C-058-HG0-ANNNNN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch Rexroth MHP112C-058-HG0-ANNNNN is a synchronous motor. It is part of MHP motor family which is designed for use with PowerDrive servo drives. The rated characteristic motor speed is 4000 RPM and its base speed is 2500 RPM. Maximum speed of the MHP112C-058-HG0-ANNNNN motor is 4500 RPM. The maximum theoretical torque is 148 Nm and the maximum rated motor current is 169.7 Amps. Moment of inertia of the motor rotor is 273 x 10-4 kg m2. Number of pole pairs on the motor is 4 and the rated nominal motor frequency is 167 Hertz. The power connector is located on top of the motor and points toward side A of the motor. The MHP112C-058-HG0-ANNNNN is cooled through natural convection. MHP motors with liquid cooling are also available. The motor enclosure has IP65 protection rating.

Size of the MHP112C-058-HG0-ANNNNN is 112 and its length is C. The Bosch code for the motor winding it 058. Other features of the motor include built-in incremental encoder with 2048 increments and plain motor shaft with sealing ring. Holding brake is not available on the motor but can be ordered as an option if required. For optimal operation the MHP112C-058-HG0-ANNNNN should be operated in an environment where the ambient temperature is maintained between 0 and 40 degrees Celsius and where the elevation is less than or equal to 3300 feet. If the motor is operated outside these recommended ranges then the output torque of the motor will less than the rated values i.e. the motor output will derate. To minimize the risk of equipment damage and personnel injury, the MHP112C-058-HG0-ANNNNN should only be installed and serviced by personnel possessing the requisite training and experience. This unit can be shipped globally with a one-year warranty period from Wake Industrial.

MHP112C-058-HG0-ANNNNN Documents

  • MHP112C058HG0ANNNNN
  • mhp112c-058-hg0-annnnn
  • MHP112C 058 HG0 ANNNNN

MHP112C-058-HG0-ANNNNN Technical Specifications

Driven Shaft: Plain Shaft with Sealing Ring
Encoder: Incremental
Holding Brake: Not Equipped
Windings: 58
