MHP093C-058-HG0-ANNNNN

  • Rated 4.4 (17 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911298713
  • Call for Expedited Shipping and Product Condition Options
MHP093C-058-HG0-ANNNNN Servo Motor is manufactured by Rexroth, Indramat, Bosch. This motor has a Plain Shaft with Sealing Ring shaft and windings of 58. This motor is also Not Equipped with a holding brake and has an Incremental encoder.

MHP093C-058-HG0-ANNNNN

  • Rated 4.4 (17 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911298713
  • Call for Expedited Shipping and Product Condition Options
MHP093C-058-HG0-ANNNNN Servo Motor is manufactured by Rexroth, Indramat, Bosch. This motor has a Plain Shaft with Sealing Ring shaft and windings of 58. This motor is also Not Equipped with a holding brake and has an Incremental encoder.
Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch MHP093C-058-HG0-ANNNNN is a synchronous motor. It is compatible with PowerDrive controllers. A 2048 increments incremental encoder on the motor provides the drive controller with the necessary feedback regarding the motor position. The motor is a permanent-magnet excited motor with electronic commutation.  The special magnets used in the construction of the motor allow a low inertial mass design. MHP motors can be liquid cooled, surface cooled or air cooled. The MHP093C-058-HG0-ANNNNN is a convection cooled (air cooled) motor. The motor does not include a holding brake. Optional holding brakes are available from Bosch and can be ordered if required. Power connection for the mains electrical power supply is on side A of the MHP093C-058-HG0-ANNNNN. Typical applications for drive systems that use MHP motors include printing machines, machining centers, gantry axes, textile machines and robots.

As per the motor type code, motor size is 093 and the motor length is C.  The MHP093C-058-HG0-ANNNNN has a plain motor shaft with sealing ring. Bosch provides performance specifications for MHP motors for both the 60K and 100K overtemperature conditions. The continuous torque at standstill for the MHP093C-058-HG0-ANNNNN is 23 Nm at 60K overtemperature and 28 Nm at 100K overtemperature. The rated motor power is 1.6 kilowatts at 60K overtemperature and 3.8 kilowatts at 100K overtemperature. Base speed of the MHP093C-058-HG0-ANNNNN is 2000 RPM. The peak motor speed is 6000 RPM. Theoretical peak torque for the MHP093C-058-HG0-ANNNNN is 88 Nm and peak current rating for the motor is 85.1 Amps. There are 4 pole pairs on the motor. Resistance of the motor winding is 0.16 Ohms and the rotary field inductance is 1.3 millihenry. The motor should be installed by trained personnel. This unit can be shipped globally with a one-year warranty period from Wake Industrial.


MHP093C-058-HG0-ANNNNN Documents

  • MHP093C058HG0ANNNNN
  • mhp093c-058-hg0-annnnn
  • MHP093C 058 HG0 ANNNNN
  • MHP93C-058-HG0-ANNNNN

MHP093C-058-HG0-ANNNNN Technical Specifications

Driven Shaft: Plain Shaft with Sealing Ring
Encoder: Incremental
Holding Brake: Not Equipped
Windings: 58
