MHD115C-035-PG1-AA

  • Rated 4.5 (35 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911296333
    In-Stock, Ships 3-5 Days
  • Unused Original Box Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options

The MHD115C-035-PG1-AA Magnet Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 35 and has a Multiturn Motor Encoder. The Driven Shaft for this motor is Plain and it is Equipped with a holding brake.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The servo motors in the MHD series can be combined with the digital intelligent drive controllers from Indramat to form rapid-response automation systems. They display high operational reliability and have low inertia masses. They can also be used as servo and main drive motors in applications such as machine tools, handling and mounting systems, printing and paper processing machines, and food processing and packaging machines.

The MHD115C-035-PG1-AA is a permanent magnet servo motor designed and manufactured by Bosch Rexroth. It is an MHD motor designed for maintenance-free operation with its brushless design and its use of bearings that remain grease-lubricated throughout their lifetime of operation. These bearings support the overhung mounting of pinions and belt pulleys as they are suitable for high radial loads. They have a service lifetime of 30,000 operating hours according to DIN ISO 281, provided that the permissible radial and axial forces are not exceeded. The output shaft of the motor is the plain type with a shaft sealing ring made from materials that are resistant to chemicals and oils.

The holding brake of the MHD115C-035-PG1-AA has a holding torque value of 70Nm. It is the electrically-released type and requires a rated voltage of DC 24V and a rated current of 1.29A. The motor is equipped with temperature sensors in its windings that prevent damage due to thermal overload and is cooled by natural convection and surface cooling. It has 4 pole pairs and a characteristic motor speed of 3,000 revolutions per minute. Its maximum theoretical torque is 231Nm, and its peak current is 265.0A. Its housing is completely sealed and has an Ingress Protection rating of IP 65.

  • MHD115C035PG1AA
  • MHD115C 035 PG1 AA
  • mhd115c-035-pg1-aa

MHD115C-035-PG1-AA Technical Specifications

Product type: Motor
Max temperature: 40 °C
Motor type: Synchronous
Feedback: Digital servo feedback with integrated encoder
Shaft: Plain
Shaft seal: Yes
Holding brake: 70 Nm
Power connector: Side A
Housing design: Natural convection and surface cooling
Protection rating: IP65

Frequently Asked Questions about MHD115C-035-PG1-AA


Q: What are typical MHD motor applications?

A: MHD motor applications include machine tools, printing and paper industries, handling and automation, and packaging machines and food.

Q: What are MHD motor advantages?

A: MHD motor advantages include high reliability, maintenance-free operation, IP65 or higher protection rating, overload protection, high dynamics, easy cabling, and quick startup.

Q: What are MHD motor components?

A: MHD motor components include shaft, stator with winding, bearings, encoder, shaft with sealing ring, rotor with magnets, and optinal holding brake.

Q: How can you identify the motor?

A: A type label attached to the motor housing enables easy identification.

Q: What happens if the maximum temperature threshold is exceeded?

A: Output of the motor will derate if the maximum temperature threshold is exceeded.

Internal Product Review

  • ‘‘MHD115C-035-PG1-AA is a high-performance servo motor with IP65 rated housing.’’
