MHD112D-027-PP0-RN

  • Rated 4.7 (6 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911291444
    In-Stock, Ships Today
  • Call for Expedited Shipping and Product Condition Options

The MHD112D-027-PP0-RN Magnet Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 27 and has a Multiturn Motor Encoder. The Driven Shaft for this motor is With Key and it is Not Equipped with a holding brake.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Bosch Rexroth is without hesitation the most reliable brand in the mechanical engineering devices industry. The company sets the benchmarks by offering top-of-the-line synchronous motors to efficient drive controllers.

The MHD112D-027-PP0-RN model is commonly found in a variety of motion control systems and automated machines. The motor contains an output shaft having keys with the sealing ring present on top of it and the fluid present at the output shaft may enter and harm the motor if the motor is not placed according to the IM V3 design. Because of the IP68 protection certification and F class insulation, the MHD112D synchronous motor is completely protected from microscopic dust particles and water jets blasted by the nozzles. During surface cooling, the model generates 15.2 of power when operating at 27.6 A of rated current and 133 Hz of rated frequency. The model's winding inductivity and resistivity are 5.65 mH and 0.35 ohms, respectively, with a moment of inertia of 350 x 10-4 kgm2. The motor's voltage and torque constants at 20 degrees Celsius are 154.5 V/1000min-1 and 1.7 Nm/A, respectively. The MHD112D synchronous motor during standstill operation has a constant torque of 57 Nm with continuous current use of 40.2 A during natural cooling and at a temperature of 100 K.

The model MHD112D-027-PP0-RN contains a power connection on the right side of the hosing and is designed in such a way that its housing suits both surface and natural cooling. The model weighs 56 kilograms and contains a thermal time constant of 40 minutes during surface cooling and 90 minutes during natural cooling. The motor (MHD112D-027-PP0-RN) contains digital servo feedback with an integrated multiturn absolute encoder and must be utilized within the defined environmental conditions to get its full functionality.

  • MHD112D027PP0RN
  • MHD112D 027 PP0 RN
  • mhd112d-027-pp0-rn

MHD112D-027-PP0-RN Technical Specifications

Driven Shaft: With Key
Holding Brake: Not Equipped
Motor Encoder: Multiturn
Winding Code: 27
