MHD112B-048-NP1-BN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911283437
  • Stock: Call for Quote
The MHD112B-048-NP1-BN Magent Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 48 and has a Digital Motor Encoder. The Driven Shaft for this motor is With Key and it is Equipped with a Holding Brake.

MHD112B-048-NP1-BN

  • {{ 'Rated ' + avg.toFixed(1) + ' (' + ratingCount + ' total ratings)' }}
  • {{ message }}
  • MPN: R911283437
  • Stock: Call for Quote
The MHD112B-048-NP1-BN Magent Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 48 and has a Digital Motor Encoder. The Driven Shaft for this motor is With Key and it is Equipped with a Holding Brake.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Exchange
Call to find out about our exchange credit for your defective unit.
Sell Us Your Surplus
Have a MHD112B-048-NP1-BN to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

The MHD112B-048-NP1-BN Bosch Rexroth synchronous motor has its power connection on the B side. This motor has a keyway shaft designed in compliance with DIN 6885-1 specifications. The shaft is equipped with a shaft sealing ring. The product also features a 22Nm holding brake. It has a Class F insulation in accordance with DIN VDE 0530 specifications. The unit has a rated frequency of 187Hz and a rated speed of 2,800min-1. It also has a winding inductivity of 3.1mH and a winding resistance of 0.22 Ohm at 20°C. The brushless design of the motor offers the assurance of maintenance-free operation. It features minimum heat dissipation between the exterior wall of the motor housing and the stator windings.

The synchronous motor supports easy attachment of external components or devices because of the way its flange is designed. The product has low inertia because of the special magnet materials used in its construction. The device has a torque constant of 0.88Nm/A at20°C. The source code of the unit’s software must not be changed. The motor should not be used if the maximum temperature is very high. The person operating the product must be trained and qualified to ground the equipment as well as turn it on and off based on technical safety regulations.

The supply mains of the motor should always be firmly and permanently connected to the safety conductor. The motor brake that is controlled by the drive controller directly does not offer enough assurance of personal safety. The holding brake has a 3.6 x 10-4 moment of inertia and weighs 1.1kg. The device has a voltage constant of 80V/1,000min-1. The product features an overall length of 375mm. The O-rings must be properly seated when the motor flange socket covers are mounted with a sealing air connector. The synchronous motor is backed by a warranty period of one year and can be sent to any location worldwide.

MHD112B-048-NP1-BN Documents

  • MHD112B 048 NP1 BN
  • MHD112B048NP1BN
  • mhd112b-048-np1-bn

MHD112B-048-NP1-BN Technical Specifications

Driven Shaft: With Key
Holding Brake: Equipped
Motor Encoder: Digital
Winding Code: 48
