MHD093B-035-PG1-RA

  • Rated 4.5 (12 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911292558
    In-Stock, Ships 3-5 Days
  • Unused Original Box Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options

The MHD093B-035-PG1-RA Magnet Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 35 and has a Multiturn Motor Encoder. The Driven Shaft for this motor is Plain and it is Equipped with a holding brake.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch Rexroth MHD093B-035-PG1-RA is a MHD series synchronous motor. In combination with Bosch drive controllers, the motor can be used for a wide range of applications that involve machine tools, handling, automation, food processing and packing machines. Features that are provided on the MHD093B-035-PG1-RA include digital servo feedback with integrated multiturn absolute encoder, plain shaft with sealing ring and a 22 Nm holding brake. The motor cools via convection cooling. This means that active devices such as fans and blowers are not required to force air across the surface of the motor. Therefore the cost of system installation and operation is reduced. However proper ventilation should be ensured so that the ambient temperature remains within the recommended range of operating temperatures. The permissible range of temperature is 0 to 40 degrees Celsius.

The maximum setup height of the MHD093B-035-PG1-RA should not exceed 1000 meters. The housing of the motor belongs to the IP65 class. This rating indicates a very good level of protection from both liquids and solids which allows motor installation near operating machinery. The shaft seal is a contributing factor to this good IP rating. The shaft seal deteriorates during motor operation and should be inspected at regular intervals. The holding brake on the MHD093B-035-PG1-RA is designed to prevent shaft movement till the application of a 24 Volts DC signal. The holding brake is included as a safety feature. The power connector is located on the right side of the motor housing. The motor is designed for a maximum speed of 4500 RPM. The insulation class of the MHD093B-035-PG1-RA is F as per DIN VDE 0530 Part 1. Shipping weight of the motor is 19 kilograms.

  • MHD093B035PG1RA
  • MHD093B 035 PG1 RA
  • mhd093b-035-pg1-ra
  • MHD93B-035-PG1-RA

MHD093B-035-PG1-RA Technical Specifications

Driven Shaft: Plain
Holding Brake: Equipped
Motor Encoder: Multiturn
Winding Code: 35
