MHD090B-035-NP1-UN

  • Rated 4.6 (30 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911280471
    In-Stock, Ships 3-5 Days
  • Unused Original Box Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options

The MHD090B-035-NP1-UN Magnet Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 35 and has a Digital Motor Encoder. The Driven Shaft for this motor is With Key and it is Equipped with a holding brake.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The Bosch MHD090B-035-NP1-UN is a motor with 090 motor size which equates to 140 millimeters flange size and 110 millimeters centering diameter. The motor flame length is B which equates to 12.0 Nm continuous torque while the motor is at standstill. The MHD090B-035-NP1-UN motor comes with integrated encoder: feedback type available on the motor is digital servo feedback which allows relative position detection. Option available on the motor for enabling connection with plane machine elements is a shaft with key as per DIN 6885-1. The shaft also includes a sealing ring. The characteristic speed and maximum speed which are supported by the motor are 2500 RPM and 5000 RPM respectively. Peak current rating of the motor is 49.5 Amps. Number of pole pairs on the motor are 4.

At 60 K, the rated motor speed is 3000 RPM, the rated torque is 7.2 Nm, the rated current is 4.7 Amps, the rater power output is 2.8 kilowatts, the rated voltage is 354 Volts and the rated line frequency is 200 Hertz. At 100 K, the rated motor speed is 3000 RPM, the rated torque is 10.2 Nm, the rated current is 6.7 Amps, the rater power output is 4.0 kilowatts, the rated voltage is 369 Volts and the rated line frequency is 200 Hertz. Mechanical parameters for the MHD090B-035-NP1-UN include 43.0 x 10-4 kg m2 moment of rotor inertia, maximum theoretical torque of 43.5 Nm, maximum speed of 5000 RPM, motor weight of 14 kilograms and maximum recommended altitude for installation of 1000 meters. The MHD090B-035-NP1-UN includes a 11 Nm rated holding brake. Housing of the motor is designed for surface cooling. The electrical power connector can be rotated by 270 degrees. The MHD090B-035-NP1-UN can be shipped to any address globally with a one-year warranty period from Wake Industrial.

  • MHD090B035NP1UN
  • MHD090B 035 NP1 UN
  • mhd090b-035-np1-un
  • MHD90B-035-NP1-UN

MHD090B-035-NP1-UN Technical Specifications

Driven Shaft: With Key
Holding Brake: Equipped
Motor Encoder: Digital
Winding Code: 35
