MHD071B-035-PP3-UN

  • Rated 4.5 (6 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911307875
    In-Stock, Ships 3-5 Days
  • Unused Original Box Pricing Available!
    Request a Quote!
  • Call for Expedited Shipping and Product Condition Options

The MHD071B-035-PP3-UN Magnet Motor is manufactured by Rexroth Indramat Bosch. This motor has a Winding Code of 35 and has a Multiturn Motor Encoder. The Driven Shaft for this motor is With Key and it is Equipped with a holding brake.

Preparing your secure checkout page...

Request A Quote

Please fill out the form below and a representative will contact you with a formal quote.

Request A Repair

Please fill out the form below and a representative will contact you with a formal quote.

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The MHD071B-035-PP3-UN is a synchronous servo motor in the MHD series from Bosch Rexroth Indramat. It leverages a surface cooling mechanism with a motor overtemperature of 60/100 K. The continuous current of the MHD071B-035-PP3-UN at a standstill is 9.5 A, and its maximum current is 28.3 A. At 20 degrees C, this unit's torque constant, winding resistance, and voltage constant are 1.38 Nm/A, 4.57 Ohm, and 125 V/1000rpm. Its winding inductivity is 23.0 mH. It features four pole pairs, and its rated speed is 2500 rpm. Also, the rated torque of the MHD071B-035-PP3-UN is 5.7 A, and its insulation is F.

The performance of the MHD071B-035-PP3-UN is characterized by high dynamics, peak torque utilization, easy cabling, high overload capacity, high-performance data, and overload protection. Also, its principal design features unique magnet designs that ensure that the motor functions efficiently and with low inertia masses. The typical use cases of the MHD071B-035-PP3-UN are evident in food processing machines, handling & automation, paper processing machines, etc. It is not suitable for use underwater or with extreme temperature variations.

The motor frame size of this unit is designated 071, which connotes a flange size of 115 mm and a centering diameter of 95 mm. At a standstill, the continuous torque of this MHD motor is 12 Nm, and its winding code is 035. The encoder utilized by this model of MHD motors is the digital servo feedback type (HSF with integrated multiturn absolute encoder) with absolute position detection and over 4096 revolutions. Its output shaft has a keyway with a shaft sealing ring. Its power and feedback output connector can rotate within a range of 270o.

  • MHD071B035PP3UN
  • MHD071B 035 PP3 UN
  • mhd071b-035-pp3-un
  • MHD71B-035-PP3-UN

MHD071B-035-PP3-UN Technical Specifications

Driven Shaft: With Key
Holding Brake: Equipped
Motor Encoder: Multiturn
Winding Code: 35
