Product Description:

The MDD095B-N-060-N2L-110PA0 synchronous motor is built by Bosch Rexroth Indramat and belongs to the MDD Synchronous Motors series. It is intended for use with digital drive controllers, where it converts electrical energy into controlled rotary motion for automation axes in packaging, printing, and material handling equipment. This motor fits the 95 mm frame class indicated by the part code, so it suits systems that need a compact servo package with predictable mounting geometry. Its general layout supports precise motion control in applications that depend on repeatable acceleration, stable speed control, and accurate positioning over continuous operating cycles.

A centering pilot of 110 mm lets the flange locate accurately on mounting surfaces and helps minimize radial misalignment during installation. The rotor uses motor length code B, giving the motor an active stack suited to the torque available at a maximum speed of 6000 rpm. Position and velocity are returned through Digital servo feedback (DSF), which gives the controller high-resolution data for stable speed regulation and precise positioning. For environments exposed to emulsions or fine dust, the drive-side output is equipped with a shaft seal to limit lubricant loss and reduce contaminant ingress.

The motor is supplied without a blocking brake, so any holding function must be provided by external mechanics when the axis is at a standstill. Power and feedback leads exit on side A through a keyed connector, which supports secure electrical connection and straightforward cable routing. The motor uses Standard dynamic balancing, helping keep vibration within normal operating limits when the shaft is properly coupled. The drive-side shaft has a keyway profile for positive torque transmission, while side B has no shaft extension.
