Product Description:

The MDD093C-N-030-N2M-110PA2 is a synchronous servo motor built by Bosch Rexroth Indramat within the MDD Synchronous Motors series. Intended for use with digital drive controllers, the unit converts commanded current into precise rotary motion for positioning axes, packaging equipment, and handling modules. The motor supports closed-loop torque and speed control during repetitive industrial cycles. Power and feedback connections are arranged for direct integration into automated multi-axis systems, helping keep wiring orderly around the machine.

The motor’s nominal shaft velocity reaches 3000 rpm, giving the axis a high operating speed for indexing and continuous-motion tasks. An internal brake supplies 22 Nm of holding torque, so vertical or suspended loads can remain fixed when the controller is disabled. Accurate concentric mounting is promoted by a 110 mm centering diameter that fits standard flange faces. Power and feedback conductors are routed toward Side A, which can simplify cable routing in compact machine layouts. Motion data are returned through digital servo feedback (DSF), allowing the drive to regulate current and velocity with high resolution while standard balancing helps reduce vibration during operation.

The motor uses a connector interface for the motor leads and encoder lines, allowing quick connection during installation and service. Position information is generated by an integrated multiturn absolute encoder, so the controller can retain position over multiple revolutions after power returns. The output shaft uses a keyway to transmit torque securely to couplings or pulleys, and a shaft seal helps protect the bearing area from contamination and lubricant loss. The C length code indicates a longer active motor section for increased continuous torque, while the standard housing and the lack of a side-B shaft end help keep the overall package easier to guard in enclosed machinery.
