The Bosch Rexroth Indramat MDD093C-N-030-N2M-110GB0 is part of the MDD Synchronous Motors series and is designed for digital drive controllers. It has a plain shaft with a centering diameter of 110 mm, a nominal speed of 3000 min⁻¹, and features an integrated multiturn absolute encoder for feedback. The motor uses a standard housing and connection direction is on Side B.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MDD093C-N-030-N2M-110GB0 is a brushless AC servo motor produced by Bosch Rexroth Indramat for the MDD Synchronous Motors series. Designed for integration with digital drive controllers, this motor converts electrical commands into controlled rotary motion for indexing tables, packaging stations, and material-handling axes. As a synchronous design with permanent-magnet excitation, it delivers constant torque over a wide speed range while maintaining the position accuracy required in industrial automation. The motor layout also supports responsive acceleration and stable motion during repeated starts, stops, and speed changes.
It reaches a nominal speed of 3000 rpm, enabling direct coupling to gearless drive trains where high rotational speed is required. The flange has a centering diameter of 110 mm, so alignment with machine housings remains repeatable. All power and signal conductors exit on side B because the connection set is mounted there. A round industrial connector carries the phase leads and encoder lines, helping keep wiring orderly in enclosed machine spaces. Position data is returned through Digital servo feedback (DSF), and absolute position is retained by an integrated multiturn absolute encoder. The C length code adds extra stack depth to the 093 frame, which supports higher continuous torque without changing the mounting geometry.
The motor is supplied without a blocking brake, so braking torque must be provided by the drive or by external mechanics during power-off states. A factory-installed shaft seal helps protect the internal bearings against splash and dust when the motor is mounted to suitable machine hardware. The output uses a plain shaft in a standard single-ended configuration, while the opposite side remains closed. Standard dynamic balancing reduces vibration at operating speed, and the housing dissipates heat by natural convection during normal operation. This arrangement keeps the motor exterior straightforward for coupling to pulleys, pinions, or similar transmission elements.
Frequently Asked Questions about MDD093C-N-030-N2M-110GB0:
Q: What type of encoder is included in the MDD093C-N-030-N2M-110GB0 motor?
A: The MDD093C-N-030-N2M-110GB0 uses an integrated multiturn absolute encoder for precise position feedback.
Q: What feedback mechanism is used by the MDD093C-N-030-N2M-110GB0?
A: This motor is equipped with a digital servo feedback (DSF) system for accurate monitoring and control.
Q: What is the nominal speed of the MDD093C-N-030-N2M-110GB0 motor?
A: The nominal speed of this model is 3000 min⁻¹, supporting efficient motor operation.
Q: What shaft features are offered by the MDD093C-N-030-N2M-110GB0 motor?
A: This unit comes with a plain shaft and is supplied with a shaft seal to help prevent the ingress of dust or liquids.
Q: Does the MDD093C-N-030-N2M-110GB0 feature a holding brake?
A: The motor is manufactured without a blocking brake, so it does not provide holding brake functionality.
