Product Description:

The MDD093C-N-030-N2L-130GL0 belongs to the MDD Synchronous Motors series produced by Bosch Rexroth Indramat. It is a rotary servo motor intended for integration with digital automation platforms where precise velocity and position control are required. By coupling directly to a driven machine element, the motor converts electrical energy from a matched drive into regulated mechanical torque for assembly lines, packaging stations, and material-handling axes. This arrangement supports repeatable motion in applications that depend on accurate response during acceleration, steady running, and controlled stopping.

The motor has a nominal speed rating of 3000 rpm, which is the standard rotational speed it can sustain under rated load. A centering diameter of 130 mm provides the pilot fit that aligns the housing with the machine flange and helps maintain accurate mounting. Position data are returned through digital servo feedback, allowing the drive to compare commanded motion with actual shaft position during operation. Because the unit is supplied without a blocking brake, any holding requirement must be handled by the drive or by external locking hardware. The output uses a plain shaft, which allows clamping hubs or shrink-fit couplings to be mounted without a keyway.

The motor has a length code of C and a frame size of 093, giving it a size that suits many indexing and handling axes without an oversized footprint. Electrical and signal conductors leave through a left-side connection that uses a circular industrial connector, which helps keep cable routing clear in closely spaced machine layouts. A fitted shaft seal helps block dust and cooling oil from entering the bearing cavity during normal operation. Standard rotor balancing supports smooth rotation, and the cast housing follows the usual enclosure shape used for this motor line. These features allow the motor to fit cleanly into automated equipment that requires stable servo performance and practical installation.
