Product Description:

The MDD093C-N-020-N2M-110PB2 is a synchronous servo motor manufactured by Bosch Rexroth Indramat as part of the MDD Synchronous Motors series. It is intended for use with digital drive controllers where closed-loop control of torque and speed is required for positioning tables, packaging machinery, or material-handling equipment. The motor integrates a multiturn encoder and a blocking brake so it can report absolute position to the drive and hold loads when power is removed. This combination makes it suitable for vertically oriented axes and other applications that require both accurate positioning and secure standstill holding.

This model’s centering flange has a diameter of 110 mm, which helps maintain concentric alignment with gearboxes or mounting brackets. Its nominal operating speed is rated at 2000 rpm, which is the continuous rotational speed the motor can produce under rated load and voltage. A blocking brake supplies 22 Nm of static holding torque to keep the shaft fixed during power-off conditions. Position feedback is provided by an integrated multiturn absolute encoder, allowing the controller to detect shaft angle across multiple revolutions without re-homing. That feedback is transmitted through digital servo feedback, which supports high-resolution monitoring of position and velocity in closed-loop motion control.

Cabling enters the housing on Side B, which helps keep power and signal connections clear of moving machine elements. Electrical power and feedback lines terminate on a rugged connector, allowing cable connection without disassembling enclosure glands. The output shaft uses a keyway interface so torque can be transferred directly into couplings or pulleys without slip, and a shaft seal helps limit the ingress of dust or coolant. The motor has Motor Length Code C, which provides a deeper stator stack for higher continuous torque while retaining the standard housing format and balancing grade.
