Product Description:

The MDD093C-N-020-N2L-110PL0 is an AC permanent-magnet servo motor manufactured by Bosch Rexroth Indramat within the MDD Synchronous Motors series. Designed for digital drive controllers, it converts commanded current into precise rotary motion for axes in machine tools, packaging lines, and material-handling systems. Its housing matches motor size 093 with length code C, making it suitable for installations that need a mid-length motor with medium torque output. The permanent-magnet design supports responsive torque production and stable speed control when paired with a compatible servo amplifier.

Its nominal speed of 2000 rpm is the continuous operating velocity available before field weakening is required. A centering diameter of 110 mm aligns the flange accurately to the driven machine and helps keep coupling runout low. Position and velocity are controlled through digital servo feedback (DSF), which sends feedback data to the drive in real time for stable closed-loop operation. Power and feedback conductors terminate through a connector on the left side of the housing, which supports orderly cable routing in compact installations. This layout also keeps the electrical connection area accessible when the motor is mounted close to surrounding machine structure.

The output shaft uses a keyway so torque can be transmitted through a positive mechanical connection. That shaft arrangement is commonly used with pulleys, couplings, and other driven elements that must resist slip under load. The motor is supplied without a blocking brake, so any holding function must be provided by external equipment when the axis is at rest. It has a standard housing with standard vibration-class balancing for general industrial duty. A front oil lip allows operation with a shaft seal, which helps limit the ingress of dust or fluid into the bearing area during continuous use.
