Product Description:

The MDD093C-N-020-N2L-110GA0 is a synchronous servo motor produced by Bosch Rexroth Indramat within the MDD Synchronous Motors series. Classified as a motor for digital drive controllers, it converts regulated current from the drive into controlled torque and speed for industrial automation axes. The unit forms the electromechanical link between the drive electronics and the machine load, enabling precise positioning and repeatable motion cycles in packaging lines, transfer systems, and general material-handling equipment. In closed-loop operation, this arrangement allows the connected drive to correct motion deviations caused by changing loads and acceleration demands.

Its rated speed of 2000 rpm sets the continuous operating limit that the drive can command without thermal derating. A centering diameter of 110 mm pilots the motor into the mounting flange, maintaining coaxial alignment with bearings and couplings. All power and feedback conductors exit on Side A, so space must be reserved on that face for cable routing. Connection is made through a keyed connector, which allows secure mating without rewiring terminals. The motor is delivered without a blocking brake, so static holding must be provided by external mechanical locking or controlled drive torque when required.

Position data reach the controller through digital servo feedback (DSF), allowing tight speed and position loops during dynamic motion. Length code C uses a deeper stator stack, and when combined with frame size 093 it supports higher continuous torque than shorter versions of the same motor platform. The motor has a single plain output shaft, while the opposite end remains closed. The working end is fitted with a shaft seal to reduce lubricant loss and limit the entry of airborne contaminants. This single-shaft arrangement supports compact drive-train layouts where no rear shaft extension is needed.
