Product Description:

The MDD093B-N-030-N2M-110PA2 is a synchronous servo motor manufactured by Bosch Rexroth Indramat within the MDD Synchronous Motors series. Classified as a motor for digital drive controllers, it converts electrical energy into controlled rotary motion for positioning tables, gantries, and other automated axes. The unit’s standard housing and balancing allow it to be integrated without special mounting procedures, and its keyed output shaft mates directly with couplings or gearboxes used throughout industrial automation cells.

With size code 093 and length code B, the motor presents a compact frame that still offers a centering diameter of 110 mm for precise seating on machine plates. All power and feedback conductors exit on side A through a pre-wired connector, reducing cabinet depth requirements. The keyed shaft corresponds to the specified shaft type and is supplied without a secondary shaft end, simplifying axial layouts. Under rated conditions, the rotor reaches 3000 rpm, while a continuous standstill torque of 14.5 Nm can be maintained without thermal overload. Standard mechanical balancing minimizes vibration at any speed, and the enclosure’s standard housing resists the contaminants normally encountered in production areas.

For static load holding or emergency stops, a blocking brake delivers 22 Nm of torque and engages whenever supply power is removed. Position data are captured by the motor’s integrated multi-turn absolute encoder, and those signals are transmitted as digital servo feedback (DSF) to the drive controller for closed-loop regulation. This arrangement lets the drive retain position information after power cycles and monitor shaft motion continuously during operation. A fitted shaft seal protects the interior bearings against coolant and dust intrusion, while the connector supports secure cable attachment.
