Product Description:

The MDD093B-N-020-N2L-110GL0 is a synchronous servo motor manufactured by Bosch Rexroth Indramat for the MDD Synchronous Motors series. It is intended for use with digital drive controllers, where it converts commanded current into mechanical rotation for positioning and velocity tasks in packaging lines, gantry axes, and other automated equipment. This operating role lets the motor support closed-loop motion control during repeated starts, stops, and speed changes. Its size 093 frame with B length fits installations that use compatible drive modules in multi-axis CNC and material-handling cells.

This motor delivers a continuous standstill torque of 14.5 Nm, allowing the axis to support static loads without overheating when the shaft is motionless. That output is useful on indexing axes that must resist load disturbances between moves. The motor has a nominal speed of 2000 rpm, which gives the drive a stable rated operating speed for continuous duty. A centering diameter of 110 mm provides an accurate reference surface for mounting on machine frames, and the alignment shoulder helps the housing seat correctly against mating parts. The motor uses a plain shaft without a secondary shaft end, which simplifies coupling to gearboxes or belt pulleys.

Feedback to the drive is provided through digital servo feedback (DSF), which supplies high-resolution position data for closed-loop regulation and accurate speed correction. Power and feedback connections face left, and the motor uses a rugged connector interface that supports secure cable attachment. The unit is built without a blocking brake, so applications that must hold position at a stop need external clamping or drive-generated torque. A factory-installed shaft seal helps protect the internal bearings from splash fluids, and the standard housing with standard balancing suits general-purpose machine installations where forced ventilation or liquid cooling are not required.
