Product Description:

The MDD093A-N-030-N2L-110PA2 is a synchronous servo motor produced by Bosch Rexroth Indramat for the MDD Synchronous Motors series. Classified as a motor for digital drive controllers, it converts regulated electrical power from an inverter into precise rotary motion for automated positioning and velocity loops. The unit is used in packaging stations, handling robots, and machine-tool axes where closed-loop speed control and repeatable torque delivery are required.

At a nominal speed of 3000 rpm, the rotor stays synchronized with the drive frequency, giving predictable cycle times. A continuous standstill torque of 9.2 Nm permits the axis to support static loads without reaching thermal limits. The mounting pilot measures 110 mm, ensuring concentric alignment with adjacent mechanics. Power and feedback cables exit on side A, simplifying wiring layouts in multi-axis cabinets. Position information comes from digital servo feedback (DSF), which the controller samples for high-resolution velocity and position loops. The motor has size 093 and length code A, which correspond to a compact active lamination stack. Standard balancing controls residual vibration, and the shaft end is supplied in the normal form without a side-B extension. A keyed output couples torque directly, and a circular connector provides the electrical interface.

The integrated blocking brake delivers 22 Nm of holding torque so vertical or suspended loads remain secure when power is removed. A factory-installed shaft seal helps prevent lubricant loss and shields the bearings from dust or spray. The exterior follows a standard housing outline that matches the series mounting profile and keeps installation straightforward. Because the brake, seal, and cable routing are contained within this outline, the motor can be positioned close to other components while keeping the overall envelope compact and minimizing cable bends.
