The Bosch Rexroth Indramat MDD090C-N-030-N2L-110PA0 is a motor from the MDD Synchronous Motors series, designed for use with digital drive controllers. It has a nominal speed of 3000 min⁻¹ and delivers a continuous torque at standstill of 10.4 Nm. The motor features a 110 mm centering diameter, a shaft with keyway and seal, and uses digital servo feedback.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MDD090C-N-030-N2L-110PA0 is a synchronous servo motor in the MDD Synchronous Motors series from Bosch Rexroth Indramat. It is supplied as a motor for digital drive controllers and integrates into closed-loop positioning axes on assembly lines, packaging units, and machining centers. The C length code paired with the 090 frame size gives the motor a mid-range profile for rotary duties in industrial automation. Its synchronous design supports accurate speed regulation and repeatable positioning when paired with a compatible controller. This makes it suitable for indexing, feed axes, and other applications that require controlled acceleration and consistent motion over repeated cycles.
Its nominal speed is 3000 rpm, which is the maximum continuous rotational velocity at rated voltage. At standstill, the motor provides 10.4 Nm of continuous torque, allowing stable holding and low-speed operation without overheating. Mechanical fit is guided by a centering diameter of 110 mm. Installation wiring is simplified because the power and encoder plugs face side A and use a connector interface. Feedback is managed by digital servo feedback (DSF), so the controller receives high-resolution position data for accurate speed and position control. Standard balancing helps reduce vibration at operating speed, and the housing uses the standard form factor for common machine mounting arrangements.
The shaft is machined with a keyway and protected by a shaft seal, giving secure torque transfer and helping keep oil away from the output end. Delivered without a blocking brake, the motor relies on drive holding torque or an external brake when power is removed. The shaft end is present only on the drive side, so there is no side B extension to complicate coupling alignment with pulleys or gearboxes. This layout suits drive trains that use external holding methods and do not need a secondary shaft extension.
Frequently Asked Questions about MDD090C-N-030-N2L-110PA0:
Q: What is the continuous torque at standstill for the MDD090C-N-030-N2L-110PA0 motor?
A: The MDD090C-N-030-N2L-110PA0 motor delivers a continuous torque of 10.4 Nm at standstill.
Q: What type of motor feedback does the MDD090C-N-030-N2L-110PA0 use?
A: This model features digital servo feedback (DSF) for precise motor position monitoring.
Q: Which direction is the electrical connection located on the MDD090C-N-030-N2L-110PA0?
A: The connection direction for this motor is specified as Side A.
Q: What type of shaft and seal does the MDD090C-N-030-N2L-110PA0 have?
A: This motor is equipped with a shaft featuring a keyway and a shaft seal for added protection.
Q: What is the nominal speed of the MDD090C-N-030-N2L-110PA0 synchronous motor?
A: The MDD090C-N-030-N2L-110PA0 operates at a nominal speed of 3000 min⁻¹.
