MDD090B-N-020-N2L-110PB0
MPN: R911249492
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships Today
The MDD090B-N-020-N2L-110PB0 Servo Motor is manufactured by Bosch Rexroth Indramat. This unit operates with a 2000 Min nominal speed, Digital Servo Feedback, a(n) Output Shaft with Keyway, and it is Not Equipped with a blocking brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The Bosch MDD090B-N-020-N2L-110PB0 is a synchronous motor. A barcode sticker on the motor packaging helps to identify the motor. The information on the sticker includes the motor type designation and other relevant information. A name plate is also attached to the motor housing. The information listed on the name plate includes the motor type code, the serial number, torque and current ratings for the respective cooling methods, protection rating, and holding brake specifications. The MDD090B-N-020-N2L-110PB0 is supplied without a holding brake. Motor features include a shaft with keyway, support for digital servo feedback, power connector on side B of the housing and a standard housing that is suited to natural convection or surface cooling. During storage, the MDD090B-N-020-N2L-110PB0 motor should be kept in a dust-free and shock-free environment. The permissible ambient temperature for storage is -20 to 85 degrees Celsius.
There are plastic protective covers on the connector housing and the output shaft. These should only be removed just prior to motor mounting. The output shaft should be protected from impacts and heavy loads, otherwise the bearings on the motor could get damaged. Suitable lifting devices should be used for motor transport. Only trained personnel should mount the motor to the machine. Only a fully trained electrician should start up the motor and connected machine. The nominal speed rating of the MDD090B-N-020-N2L-110PB0 is 2000 RPM. Protection rating of the motor is IP65. The recommended working temperature is 0 to 45 degrees Celsius. The recommended installation site altitude is 0 to 1000 meters. Centering diameter of the MDD090B-N-020-N2L-110PB0 is 110 millimeters. Weight of the motor is approximately 18 kilograms. The housing of the MDD090B-N-020-N2L-110PB0 is painted black.
