MDD071B-N-060-N2T-095GA0
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911273832
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
-
In-Stock, Ships 3-5 Days
The MDD071B-N-060-N2T-095GA0 Servo Motor is manufactured by Bosch Rexroth Indramat. This unit operates with a 6000 Min nominal speed, Digital Servo Feedback with integrated multiturn absolute encoder , a(n) Plain Output Shaft, and it is Not Equipped with a blocking brake.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
Bosch Rexroth is a well-known industrial equipment maker. The company manufactures AC servo motors, synchronous motors, drive controllers, drive converters, and other components for a number of industries.
The MDD071B-N-060-N2T-095GA0 model uses 4.4 A of continuous current and produces 15 Nm of continuous torque in a standstill position and has a winding inductance of 2.2 mH. The motor has a black primary coat (RAL 9005) for acid protection and a plain shaft with a sealing ring to keep lubrication in place. The MDD071B AC servo motor weighs 8.8 kilos without attachments and is compact and robust, allowing it to be used in confined quarters. The motor has a moment of inertia of 8.9 x 10-4 kgm2 and a centering diameter of 95 mm, despite its modest size. During an inrush operation, the model generates a theoretical torque of 4.4 Nm while using 7.3 A of peak current and rotating at a maximum rotational speed of 6000 revolutions per minute. The MDD071B AC servo motor has a 45-minute thermal time constant and an N balancing class. The motor has a winding resistance of 0.37 ohms and torque constant of 0.29 Nm/A at 20 degrees Celsius.
The model MDD071B-N-060-N2T-095GA0 is IP65 rated and has an insulation level of F, making it ideal for use in tough conditions. The operating temperature of the model should be between 0 and +45 degrees Celsius, and the transporting temperature should be between -20 and +80 degrees Celsius. The power connector for the servo motor is on the A-side of the enclosure and should be grounded using PG threaded joints. The motor has digital servo feedback with a multiturn absolute encoder. This device (MDD071B-N-060-N2T-095GA0) comes with a replacement warranty from Wake Industrial.
