Product Description:

The Bosch Rexroth Indramat MDD065D-N-060-N2L-095GB1 is a synchronous servo motor in the MDD Synchronous Motors series. It is intended for use with digital drive controllers, which regulate current precisely during changes in speed and load. In that role, the motor converts electrical commands into controlled rotary motion for indexers, small pick-and-place axes, and other motion tasks in automated assembly lines. The synchronous rotor and closed-loop drive arrangement support repeatable starts, short positioning moves, and stable speed regulation across rapid production cycles.

This model reaches a nominal speed of 6000 rpm, allowing fast cycle execution when the drive issues full-speed commands. At standstill, it can deliver 2.7 Nm continuously without exceeding its thermal limit, so low-speed feed motions remain stable and sustained zero-speed loading is possible. Position and velocity are returned to the controller through digital servo feedback (DSF), which supports closed-loop correction during changes in load, direction, or commanded speed. Electrical power and feedback leads exit on side B, and the factory-installed connector provides a plug-in interface that keeps cable routing compact and orderly. The D length code gives the motor a longer active section than shorter lengths in the series, while the rigid aluminum housing supports accurate rotor alignment under dynamic motion.

Where motion must stop securely during power loss, the integrated blocking brake supplies 3.0 Nm of holding torque and engages automatically when the drive is disabled. A plain shaft allows couplings or pulleys to be mounted without keys, which simplifies the output interface where friction-locking hubs are used. The centering pilot of 95 mm supports repeatable alignment against machine flanges or gearboxes, helping the shaft axis remain accurately positioned during installation. A design with a shaft seal helps retain internal lubrication and resists splash from external coolants. The standard sealed housing and compact 065 frame let the motor fit into tightly spaced servo zones.
