Product Description:

The MAF160C-0200-FQ-C0-FK0-35-N1 is a liquid-cooled asynchronous housing motor produced by Bosch Rexroth Indramat for the MAF IndraDyn Asynchronous Motors series. As an asynchronous housing motor, it is used with a compatible drive system to regulate torque and speed for repeatable axis motion. It is suited to applications that require consistent torque and compact dimensions, such as indexing tables and continuous-duty production axes. By circulating coolant through the stator jacket, the motor transfers heat to an external chiller so it can maintain rated output in sealed cabinets where open-air cooling would be less effective.

The motor reaches a rated speed of 2000 rpm. Heat is removed by liquid cooling, and the jacket uses a 1/2 inch connection thread for coolant lines. The 0200 winding is paired with the 160 frame size and C-length housing to support this operating point in a compact package. The rotor is supported by standard bearings, and the housing includes flange and foot mounting for horizontal or vertical installation. Feedback is provided by an incremental encoder with 2048 increments and a supply voltage of 5 V, giving the drive controller precise position data. The motor is supplied without a holding brake, and the shaft has a sealing ring and a keyway for positive coupling. Internal mass balance is set to vibration level A to keep running forces low at speed.

The enclosure is rated IP65, which helps block dust and water jets. The insulation system meets class F, and operation is permitted in ambient temperatures from 0 to 40 °C. Class F insulation allows winding temperatures up to 155 °C when the motor is used within that ambient range. The rotor is balanced with a half key in accordance with DIN EN 60034-14. This balancing method gives the coupling a consistent reference condition, while the shaft seal and coolant circuit support use in washdown or oil-mist areas.
