Product Description:

The MAF130D-0200-FQ-S2-AH0-05-N1 is a liquid-cooled asynchronous housing motor built by Bosch Rexroth Indramat within the MAF IndraDyn Asynchronous Motors series. Designed for flange mounting in tightly packed production equipment, the unit converts drive-controller output into constant mechanical rotation for medium-speed conveyor sections, processing heads, or auxiliary spindles. It dissipates heat through a coolant circuit instead of relying on ambient airflow.

Its stator jacket uses liquid cooling to remove losses, permitting continuous operation at the rated speed of 2000 rpm without thermal derating. Position feedback is delivered by a single-turn absolute encoder that communicates through the EnDat2.1 interface. The measuring system provides 2048 increments and operates from an auxiliary supply of 7–12 V. The motor bolts directly to a machine plate through a flange mounting pattern, while a plain steel shaft transmits torque to couplings or pulleys. Electrical power reaches the stator windings from the A-side through a sealed connector, and Class F insulation supports elevated winding temperatures. Dynamic balance is classified as vibration grade A for typical industrial drive assemblies.

Coolant enters and exits through a 1/4 inch connection thread that is integrated into the housing casting. The housing has an IP65 rating, so process dust and low-pressure water jets do not reach internal components. The rotor runs on standard bearings, and the motor complies with DIN EN 60034-14 for vibration limits. Operation is specified for ambient temperatures from 0 to 40 °C. The design omits a holding brake and a shaft sealing ring, which suits installations that rely on external locking or overpressure devices. Mechanical geometry follows frame size 130 with a D-length stack, and winding code 0200 matches converters that deliver the required magnetic flux.
