Product Description:

The MAD160C-0150-SA-S2-AQ1-35-N1 is a three-phase servo motor produced by Bosch Rexroth Indramat for the MAD IndraDyn A Motors series. It pairs a 160 frame size with the C length option to deliver medium-power rotary motion to automated axes. Electrical and feedback connections are located on the A-side of the housing and use a connector interface, which helps keep cable routing concentrated at one end of the machine. Acting as the drive element, the motor converts commanded current into torque for positioning, speed regulation, and continuous-velocity duties on industrial machinery. That arrangement can simplify installation where access near the non-drive end is limited.

The motor reaches a rated speed of 1500 rpm, and a built-in axial fan removes heat so the 0150 winding can support continuous duty without derating. A cast housing sealed to IP65 helps block dust and low-pressure water jets, while the windings use Class F insulation to withstand elevated internal temperatures. Rotor balance follows vibration grade R, the shaft is whole-key balanced and supplied without a shaft seal to reduce friction, and a standard rolling-element bearing set supports the rotor during operation. Power and feedback are carried through a molded connector, and the EnDat interface provides 2048 signal periods for closed-loop motion control.

Position feedback is delivered by a single-turn absolute encoder EnDat2.1, and motion is secured at rest by an electrically released brake that provides 100 Nm of holding torque. The mechanical layout allows flange and foot mounting, giving flexibility when the motor is integrated into base frames or vertical plates. The unit is designed to operate in ambient temperatures of 0–40 °C without external cooling equipment, and the absolute encoder provides position availability after startup. It is suitable for indexing tables, packaging actuators, and printing cylinders that require repeatable positioning after power cycles.
