MAD160C-0150-SA-S2-AK0-05-N1 Bosch Rexroth Indramat
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911323524
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
The Bosch Rexroth Indramat MAD160C-0150-SA-S2-AK0-05-N1 is a servo motor from the MAD IndraDyn A Motors series. This model features a motor frame size of 160 with frame length C, flange mounting, and an axial fan cooling system. It is equipped with a singleturn absolute encoder EnDat2.1, has a standard bearing, and operates at a rated speed of 1500 rpm.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MAD160C-0150-SA-S2-AK0-05-N1 belongs to the MAD IndraDyn A Motors series from Bosch Rexroth Indramat. This servo motor is selected for positioning, indexing, and speed-regulated duties in automated machinery where closed-loop control is required to synchronize mechanical motion with drive commands.
The motor delivers its nominal output at 1500 rpm, a speed set by the 0150 winding and intended for medium-torque applications. Heat produced during continuous duty is removed by a Axial fan, so external liquid circuits are not necessary. Rotor position is reported through a Singleturn absolute encoder EnDat 2.1, enabling drives to read an immediate 360-degree reference without battery-backed memory. Installation is simplified by Flange mounting; the housing bolts directly to a machine wall without separate foot brackets. All power and feedback conductors exit on the designated A-side through a sealed industrial connector, keeping the opposite face clear for airflow. Output torque is transferred through a half-key balanced shaft with a shaft seal, which blocks lubricant escape and resists dust ingress while maintaining dynamic balance at full speed.
A standard bearing set supports the rotor and limits radial run-out for couplings that rely on precise alignment. The unit is graded to vibration class R, so it tolerates the elevated oscillations found on presses and indexing tables without shortening bearing life. Winding code 0150 defines the conductor gauge and turns count that pair the motor with mainstream IndraDrive inverters. Frame size 160 and frame length C provide a compact diameter-to-length ratio for retrofitting into existing mechanical envelopes, while flange dimensions conform to IEC metrics. The design is supplied without a holding brake, meaning external mechanical locks or continuous drive torque must secure static loads when power is removed.
Frequently Asked Questions about MAD160C-0150-SA-S2-AK0-05-N1:
Q: What cooling method is used in the MAD160C-0150-SA-S2-AK0-05-N1 servo motor?
A: This motor uses an axial fan for cooling, enabling efficient operation at its rated speed.
Q: What type of encoder does the MAD160C-0150-SA-S2-AK0-05-N1 motor use for feedback?
A: The MAD160C-0150-SA-S2-AK0-05-N1 provides feedback using a singleturn absolute encoder with EnDat2.1 protocol.
Q: What mounting style is included on the MAD160C-0150-SA-S2-AK0-05-N1 motor?
A: This model features a flange mounting style for secure installation.
Q: Where is the connection located on the MAD160C-0150-SA-S2-AK0-05-N1 and what type is used?
A: The connection on this motor is located on the A-side and uses a connector interface.
Q: What is the shaft type featured on the MAD160C-0150-SA-S2-AK0-05-N1 servo motor?
A: The shaft is a half-key balanced design and comes with a shaft seal.
