Product Description:

The MAD160C-0150-SA-S2-AG0-35-A1 is a servo motor manufactured by Bosch Rexroth Indramat for the MAD IndraDyn A Motors series. It is intended for closed-loop drive systems where precise torque and speed control are required to index loads, track production lines, or maintain constant process speed. The unit is built on frame size 160 with length code C, giving it the diameter and stack length needed for mid-frame power levels while still permitting installation in standard industrial machinery.

This motor delivers a rated speed of 1500 rpm, a value matched to common gear ratios and drive electronics used in conveyors and forming equipment. Thermal energy is removed by a dedicated axial fan, so continuous operation remains within allowable winding temperatures without derating. Position feedback is provided by a single-turn absolute encoder EnDat 2.1; one full revolution is captured digitally, allowing immediate position availability after power-up and simplifying homing sequences. The housing carries an IP65 protection rating, preventing dust ingress and water jets from affecting bearings or windings. The unit can operate in environments from 0 to 40 °C without supplementary cooling equipment, covering most indoor production floors. An integral connector set streamlines power, feedback, and blower wiring, and the design is supplied without a holding brake for applications that rely on mechanical clamps or static friction for standstill retention.

Mechanical integration is simplified by connections located on the A-side, keeping service loops on one face of the machine frame. The casing supports flange and foot mounting, so the motor can be installed by face coupling or baseplate anchoring depending on load-path alignment. Output torque is transferred through a smooth shaft with a shaft seal that blocks lubricant loss and contaminant entry while eliminating keyway stress points. Windings use insulation class F materials, permitting winding temperatures up to 155 °C for intermittent overloads. The vibration grade is R, and winding code 0150 matches electrical resistance and inductance to standard IndraDrive inverters.
