MAD130D-0200-SA-M2-EK1-05-N1

Product Description:

MAD130D-0200-SA-M2-EK1-05-N1 is a powerful product of the well-known MAD asynchronous box motors with squirrel cage rotor. This high-power motor produces a torque of 150N & the torque is capped at 341 N. Weighing in at 165 kg & a moment of inertia of 0.164 kgm2. The power output is 31.4 Kw & maximum output 64.4 Kw. Despite the weight the motor is compact making it installable in various places. These have various industrial application by being set up in machine tool to give rotary drive to either main spindle or servo drive.

This advanced high torque motor is manufactured by Bosch group based out of Germany. The MAD line-up features a surface ventilation by a separately connected fan unit, it has an axial fan blowing in this model. For all Indra Dyn A motors with power connection via terminal box, thread reducers for the connecting threads of the terminal box are comprised in the scope of delivery. The feedback system comprises of a multi turn absolute encoder in DAC 2.1 with 2048 increments.

This motor features a holding brake to prevent free backlash of the servo axes when not in use. The technical data of the holding brake is as follows; The holding brake is electrically relapsed. The holding brake weighs 8 kg. The transmittable torque of the holding brake 80 Nm & rated current of 1.6 A. The connection time of holding brake 50 Ms while the disconnection time of holding brake is 140 Ms. The maximum speed brake of this holding brake is 8000 rpm. The maximum permissible braking energy> is 30000 Ws. The < is F. The vibration severity grade is ?R.? It comes with a one-year warranty.
