MAD130C-0150-SA-M2-AH0-35-N1
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911333214
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
MAD130C-0150-SA-M2-AH0-35-N1 Spindle Motor manufactured by Bosch Rexroth Indramat. This motor has a cooling mode with an Axail Fan, Blowing and a Singleturn Absolute, 2048 increments encoder. It also has a mounting style of Flange and a Standard bearing.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MAD130C-0150-SA-M2-AH0-35-N1 is a top-notch servo motor manufactured by Bosch Rexroth. Efficient and long-lasting construction characterizes the servo motor. Its weight is 124.0 kg, which enhances stability and smooth performance. High-performance applications may be satisfied by the motor thanks to its power wire cross-section of 16.0 mm^2. The motor can function in a variety of conditions since it can run in a broad range of ambient temperatures, from 0 to +40 °C. Because of the motor's 155 insulation class, which guarantees dependable operation even under extreme circumstances, the windings are well-protected against high temperatures.
A significant power output is intended for the servo motor. It is appropriate for applications demanding high torque because of its ability to handle substantial loads and its rated torque of 117.0 Nm. At 18.40 kW, the motor is rated for power. A rated current of 48.9 A and a rated speed of 1500 min^-1 are intended for use with the MAD130C-0150 servo motor. Max speed (9000 min^-1) with an H bearing, max torque (275.2-Nm), and max power (37.52-kW) are the maximum capabilities of the MAD130C-0150. With brief intervals, it can manage a maximum current of 93.3 A. It has a constant torque output of 125.0 Nm when at a standstill, using 51.0 A of electricity.
The link between torque production and motor current is shown by the torque constant of 3.10 Nm/A. At a rated load, the motor takes 30 minutes to achieve 63% of its ultimate temperature, which is represented by the thermal time constant. After a 10-minute cycle, the motor reaches thermal equilibrium in intermittent operation (duty cycle S6 - 44%). The motor's power connections' capacitance to the housing is shown by the discharge capacity of 20.5 nF, and the motor's torque and speed characteristics are determined by the three pole pairs. We offer a one-year warranty when you buy from us.
