Product Description:

The MAD130B-0150-SA-C0-AG0-05-N1 is a servo motor manufactured by Bosch Rexroth Indramat as part of the MAD IndraDyn A Motors series. As a rotary actuator for closed-loop drives, it converts controlled electrical power from an IndraDrive inverter into torque for positioning tables, gantries, or packaging stations. Its design combines electronic commutation and feedback so that automation controllers can regulate speed and position with high accuracy. This makes the motor suitable for production equipment that requires repeatable motion and stable response under changing loads.

A rated speed of 1500 rpm supports moderate-torque tasks while maintaining synchronous operation with the drive. Heat is removed by an axial fan mounted on the housing, allowing full output without external cooling. The enclosure has an IP65 rating, which helps protect internal components from dust and low-pressure water jets. The motor can operate continuously in ambient temperatures from 0–40 °C. Machine builders install it with flange mounting, and the power and encoder leads exit on the A-side through a single connector interface. Standard rolling bearings support radial loads, and vibration grade R helps limit resonance during normal duty cycles.

The insulation system uses Class F materials, allowing the windings to withstand elevated operating temperatures. Winding code 0150 sets the electrical characteristics needed for rated torque at nominal current with the matching drive. The motor uses a smooth shaft with an integrated seal to help block lubricant or coolant ingress. It is supplied without a holding brake, so any stationary load must be held by the drive or by external locking hardware. Frame size 130 and frame length B provide a balance between rotor inertia and continuous power density for demanding servo applications.
