MAD130B-0050-SA-C0-DQ0-05-N1
Wake Industrial LLC is not an authorized distributor of this product.
MPN: R911334770
No Tariffs On US Orders- Straightforward Pricing: No Rush Fees, No Credit Card Fees
MAD130B-0050-SA-C0-DQ0-05-N1 Spindle Motor manufactured by Bosch Rexroth Indramat. This motor has a cooling mode with an Axail Fan, Blowing and a Singleturn Absolute, 2048 increments encoder. It also has a mounting style of Flange and a Standard bearing.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The MAD130B-0050-SA-C0-DQ0-05-N1 is a high-performance IndraDyn A generation motor manufactured by Bosch Rexroth. With robust construction and advanced specifications for reliable operation, it is one of the best MAD series motors for industrial applications. Its easy-to-service design makes sure this motor requires less maintenance. Not only this, the maintenance of this motor can be done while it is running. Pairing it with Rexroth IndraDrive controller provides an intelligent drive solution. This motor features an incremental encoder.
The rotor moment of inertia of 0.0840 kg meter square of this motor enhances speed stability and control. The mass of 105.2 kg indicates robust construction of this motor. Its rated speed and key speed are kept the same, 500 revolutions per minute (RPM). But, the maximum speed that it can handle without bearing failure is 3000 RPM. The maximum torque of 208.8 Nm makes sure it can withstand high-stress situations without damage. The maximum power it can produce is 10.25 kW. The maximum current drawn by this motor is 25.4 A, and the continuous current at standstill drawn by it is 12.8 A. The torque constant at 20 degrees Celsius of 8.49 Nm/A helps in selecting appropriate drive electronics.
This motor has black paint which is resistant to water, seawater, sewage, diluted acids, and current mineral oils. It requires fan operation for cooling which uses air currents directed across its surface by air baffles. It has a flange socket which provides a secure and stable connection point for wiring or cables. The motor is inspected before delivery to ensure it operates safely. When ordered through Wake Industrial, this motor is delivered safely and securely. Also, get a 1-year warranty with the motor.
