Product Description:

The MAD100D-0250-SA-C0-AG0-05-A1 is a servo motor produced by Bosch Rexroth Indramat within the MAD IndraDyn A Motors series. As a rotary actuator, it supplies closed-loop torque and position control for automated machinery, letting motion controllers drive mechanical axes directly without intermediate gearing. This arrangement reduces backlash and supports precise interpolation in packaging lines, pick-and-place modules, and general factory automation. In servo-driven systems, direct coupling can improve positioning consistency and simplify the mechanical layout of the axis. The motor can also be used on indexing tables, transfer stations, and synchronized handling modules where controlled acceleration is important.

The motor reaches a rated speed of 2500 rpm, so drive systems can achieve moderate throughput while staying within the continuous thermal envelope. Heat generated by the stator windings is removed by an integrated axial fan; forced airflow helps keep copper temperature below insulation limits during cyclic loading. An enclosure classification of IP65 seals out dust and low-pressure water jets, allowing installation on open machine frames. Reliable operation is maintained between 0–40 °C, which suits typical shop-floor conditions without extra cabinet conditioning. The windings use Insulation Class F, so the insulation system is suited to elevated internal temperatures during sustained operation.

Electrical and mechanical interfaces are placed on the A-side, simplifying cable routing when the motor is flange-mounted to gearboxes or machine plates. Power and feedback conductors terminate through a keyed connector, allowing secure connection without disturbing the sealing surfaces during normal service. The housing is prepared for flange mounting, which centers the motor on its pilot diameter and transfers reaction torque to the machine frame. It has a smooth shaft with a shaft seal, allowing backlash-free clamping couplings to be used while limiting lubricant migration. This layout keeps the connection area consolidated on one end of the motor, which can help in compact machine arrangements. Because the unit is supplied without a holding brake, static shaft locking must be provided by the drive or by external machine elements when power is removed.
