Product Description:

The MAD100C-0150-SA-S2-FH0-05-N1 belongs to the MAD IndraDyn A Motors series from Bosch Rexroth Indramat. It is a servo motor intended for closed-loop speed and position control in automated machinery. The unit uses a 100-frame stator with C-length laminations and winding code 0150, which suits a rated speed intended for medium-torque motion axes. As a flange-mounted model, it integrates directly with gearboxes or machine frames. It is supplied without a holding brake, so load holding must be handled by the drive or by external mechanical components.

The motor reaches a rated speed of 1500 rpm, and the housing is sealed to IP65, allowing installation where oil mist and low-pressure water jets are present. Thermal losses are removed by an integrated axial fan, which moves air along the finned surface to support continuous operation. Position feedback is provided by a single-turn absolute encoder EnDat 2.1, offering 2,048 signal periods for fine commutation and accurate position capture. Mechanical attachment uses flange mounting, which aligns the smooth shaft with couplings or pulleys while maintaining proper fit at the machine interface. This arrangement suits conveyor sections, processing spindles, and indexing tables that rely on stable speed control and repeatable positioning.

Electrical terminations are completed in a terminal box oriented on the A-side of the stator, which can simplify cable routing inside cabinets. The windings use Class F insulation, supporting the motor’s thermal duty during cyclic operation. The motor is intended for ambient temperatures of 0–40 °C, provided airflow remains unobstructed around the housing. A smooth shaft without a shaft seal minimizes drag, and the standard bearing arrangement supports moderate axial loads. Vibration grade R is used for balanced running during general automation duty.
