Product Description:

The MAD100C-0150-SA-S2-BL0-05-N1 is a servo motor produced by Bosch Rexroth Indramat for the MAD IndraDyn A Motors series. The unit delivers rotary motion for industrial automation axes that require closed-loop speed and position control. Its 100 frame housing with C length uses a half-key balanced shaft without a shaft seal, so any additional protection against oil or coolant must be provided by the connected machine.

The motor reaches a rated speed of 1500 rpm, which suits moderate-speed duties such as material handling and indexing tables. Thermal energy is removed by an integrated axial fan, helping the motor maintain continuous torque in clean-air cabinets. Power and feedback lines exit on side B through a keyed connector, which keeps cable routing organized and supports secure electrical connection. The housing is rated IP65, helping protect internal parts from dust and low-pressure water exposure. All electrical components are intended to operate within an ambient temperature range of 0 to 40 °C, which matches common industrial conditions. Standard bearings support the rotor, and winding code 0150 matches the electrical characteristics expected by compatible drive controllers.

Position feedback is supplied by a single-turn absolute encoder EnDat 2.1 with 2048 periods, allowing the drive to detect rotor position accurately after power is restored. Mechanical attachment uses flange mounting, so the motor can bolt directly to machine plates or gearboxes without additional brackets. The vibration grade of R helps reduce residual imbalance during operation, and insulation class F supports stable thermal performance in cyclic duty. The motor is supplied without a holding brake, so position retention after power removal must be handled by external clamping or by the drive system. This layout supports direct integration into servo axes where compact mounting, sealed housing, and reliable feedback are required.
