Product Description

The KSM02.1B-061C-35N-M3-HP0-ET-NN-D7-NN-FW distributed servo drive manufactured by Bosch Rexroth is one of the several drives in the KSM product group. The product has to always be installed in an industrial environment. The device may trigger injury to personnel and property damage if it is not used as intended. The unit helps in controlling and monitoring electric motors. It is used in single- and multiple-axis drive and control tasks. This drive must never be operated under water. The product is supplied with power and 42V control voltage using a KMV03 supply unit from the manufacturer. The address of the device has to be set using its H and L rotary switches.

This drive should be terminated using a terminal connector at its last connection point. The device is fitted with a tricolor LED that displays its status. The LED lights up in red when there is a system error. The servo drive does not have any analog outputs. The unit is integrated with several functionalities such as an oscilloscope function. It is meant to be deactivated and dismounted only after the main switch of the machine is switched OFF. The product must at all times be dismounted only after securing the motor and/or its blower against falling off. The KSM02.1B-061C-35N-M3-HP0-ET-NN-D7-NN-FW drive can be dispatched to any global destination of your choice.

The device replacement should be done only with a new drive of the same type. The new drive must be connected according to the illustrations in the circuit diagram. This product has a 02 series code. The unit should never be installed or operated in malfunctioning or damaged condition. It has to be programmed before commissioning so that the motor carries out the functions specific to the application. The device can be utilized in machine tools. The servo drive encompasses a one-year warranty tag.
