The Bosch Rexroth Indramat IKG4050 is part of the IKG Motor Power Cables series and features a cable diameter of 12.2 mm and a jacket made from PUR. It supports an operating voltage of 600 V AC and includes four 1.5 mm² power conductors and two pairs of 0.75 mm² control wires. This cable is suitable for drag chain use and has a matte orange jacket color specified as RAL 2003.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The IKG4050 is a motor-power cable manufactured by Bosch Rexroth Indramat within the IKG Motor Power Cables series. It supplies three-phase energy and auxiliary signals between drive inverters and servo motors, giving automated axes a single bundled connection that tolerates both stationary routing and continuous motion. By combining power cores with paired signal wires, the product reduces cabinet wiring effort and supports compact dress-pack layouts on robots and gantries.
The cable is approved for an operating potential of 600 V AC (UL), delivered through four copper conductors sized at 4x1.5 mm². A circular outside diameter of 12.2 mm allows standard gland fittings while still accommodating the two screened control pairs rated at 2×(2×0.75 mm²). When installed on moving axes, the design withstands bending to a radius of 7.5 × D without conductor fatigue, so it can be laid in long-travel cable chains. The outer sheath is molded from PUR (adhesion-free, matte), a material that resists coolants and maintains flexibility; this sheath, together with internal fillers, keeps the bundle stable in drag-chain applications. Continuous conductor temperatures up to 90 °C are permitted, and the jacket’s low-friction surface prevents stick-slip inside densely packed tracks.
Transmission quality is supported by a mutual capacitance of 0.8 nF/m, limiting reactive current at high PWM switching frequencies. Copper loop resistance is 13.3 Ohm/km at 20 °C, so voltage drop stays predictable over typical machine-tool cable lengths. For fixed routing, the assembly can be clamped to a tighter minimum bend of 5 × D, useful in compact control cabinets. Visual identification is simplified by the sheath, colored RAL 2003 (orange), which matches standard safety coding for motor circuits. Together these characteristics give the IKG4050 the mechanical endurance and electrical stability required for continuous-duty automation lines.
Frequently Asked Questions about IKG4050:
Q: Is the Bosch Rexroth Indramat IKG4050 cable designed for drag chain applications?
A: Yes, the IKG4050 cable is suitable for use in drag chains, providing flexibility for continuous motion applications.
Q: What jacket material is used on the Bosch Rexroth Indramat IKG4050 power cable?
A: The IKG4050 features a jacket made of PUR (adhesion-free, matte) which enhances durability and resistance to industrial environments.
Q: What is the operating voltage of the Bosch Rexroth Indramat IKG4050 cable?
A: The IKG4050 has a maximum operating voltage rating of 600 V AC according to UL standards.
Q: How many power conductors are present in the IKG4050 cable and what is their size?
A: This cable contains four power conductors of 1.5 mm² each for power transmission.
Q: What is the jacket color of the Bosch Rexroth Indramat IKG4050 cable?
A: The outer jacket of the IKG4050 is colored RAL 2003 (orange) for easy identification in installations.
