The Bosch Rexroth Indramat HVR03.2-W045N/S200 is a power supply unit that belongs to the HVR Power Supply Units series and supports a power output of 45 kW. It features internal air cooling with a built-in blower and operates on a mains input voltage of 3 x AC 380 V to 480 V, plus or minus 10 percent. This unit provides a regulated DC bus voltage.
To contact sales for pricing and lead time:
Payment Methods
Shipping Methods
Our Credentials
Product Description:
The HVR03.2-W045N/S200 is a power supply module from the HVR Power Supply Units series by Bosch Rexroth Indramat. Installed in central drive cabinets, the unit converts three-phase mains energy into a stabilized DC bus that feeds multiple servo inverters and regenerative braking circuits. By maintaining a constant intermediate circuit voltage, it supports coordinated motion sequences and energy exchange among connected axes in packaging lines, printing presses, and material-handling gantries. Its housing format matches Indramat drive racks for straightforward cabinet integration.
The supply stage accepts 3 x AC 380 V to 480 V and remains operational within ±10% input tolerance, allowing connection to standard factory power systems without special transformers. Cooling is provided by internal air cooling with a built-in blower, so airflow passes across heat sinks to keep internal components within their operating limits. The rectifier and chopper produce a regulated DC bus voltage for the intermediate circuit. Continuous output is 45 kW, which is suitable for multiple high-power drives and regenerative energy during deceleration. The unit is built as design version 2 for compatibility with the corresponding generation of Indramat digital drives.
The code 03 identifies the power class used with medium-frame servo amplifiers, helping match bus capacity to the number of connected axes. The module belongs to the HVR Power Supply Units series and uses the standardized mounting dimensions and shared interface connectors used in that product line. It is manufactured by Bosch Rexroth Indramat and can be integrated with HDS, DDS, or DKS drives that operate from the same DC bus. Stable intermediate-circuit support allows connected axes to exchange energy during acceleration and braking without additional converters.
Frequently Asked Questions about HVR03.2-W045N/S200:
Q: What cooling method is used by the HVR03.2-W045N/S200 power supply unit?
A: The HVR03.2-W045N/S200 uses internal air cooling with a built-in blower for temperature management.
Q: What mains input voltage range does the HVR03.2-W045N/S200 support?
A: This model is built to handle a 3-phase AC input voltage between 380 V and 480 V with a ±10% tolerance.
Q: What is the power output capacity of the HVR03.2-W045N/S200 unit?
A: The HVR03.2-W045N/S200 provides 45 kW of maximum power output.
Q: What type of output voltage does the HVR03.2-W045N/S200 deliver?
A: The output voltage type of this unit is a regulated DC bus voltage.
Q: What is the series and design version of the HVR03.2-W045N/S200 power supply?
A: The HVR03.2-W045N/S200 is designed as a series 03, design version 2 unit.
