HDS03.2-W075N-HT25-01-FW

  • Rated 4.4 (14 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The HDS03.2-W075N-HT25-01-FW Servo Controller is manufactured by Rexroth Indramat Bosch. This controller is cooled by an Internal Blower, and has a rated current of 75A. This HDS controller is not equipped with Command Communication and the Controller Family is DIAX04.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

✓ In-Stock! HDS03.2-W075N-HT25-01-FW | Rexroth, Bosch, Indramat HDS Drive Series | Image

HDS03.2-W075N-HT25-01-FW

  • Rated 4.4 (14 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • Stock: In-Stock, Ships Fast
  • Call for Expedited Shipping and Product Condition Options
The HDS03.2-W075N-HT25-01-FW Servo Controller is manufactured by Rexroth Indramat Bosch. This controller is cooled by an Internal Blower, and has a rated current of 75A. This HDS controller is not equipped with Command Communication and the Controller Family is DIAX04.

Request a Quote Request Repair

Standard Repair Time is 1 - 2 weeks. 4 Day Rush Repair options are available.

Warranty
1 Year Wake Industrial Warranty Included
Shipping
Worldwide shipping via DHL, UPS, and Fedex
Sell Us Your Surplus
Have a HDS03.2-W075N-HT25-01-FW to sell?
To Speak to a sales representative for pricing and lead time:

Product Description

Rexroth works in the industrial machinery market by producing industrial equipment. Rexroth offers an extensive portfolio of systems like gearboxes, linear actuators, I/Os, servo motors and motion controllers, creating solutions for a lot of OEMs. The HDS03.2-W075N-HT25-01-FW from Rexroth is a model of the DIAX04 HDS line of servoamplifiers for industrial automation. HDS drives are single motor electric drives meant to be connected to each other in shared DC bus fashion.

This AC drive can supply a nominal current of 40 ampere and is able to deliver to the connected motor a maximum current of 75 A for a limited amount of time. The system could be attached to an additonal motion controller using the integrated SERCOS fieldbus interface. The temperature of the environment in the surroundings of the HDS03.2-W075N-HT25-01-FW has to be in the range from 5 to 55 degrees Celsius while the module is on and should remain in the following range: -30… 85 degrees Celsius when the system is not operating.

The entire parametrization of the system can be deployed to the servodrive with the Rexroth setup software by connecting a common PC to the servo amplifier with its embedded RS-232 or RS-485 interface. Parameters can be transferred to other HDS drives along with the device firmware using the software module (this feature is particularly useful if the user is in need of a quick replacement). The servodrive is provided with a base single-channel safety STO feature. The Safe Torque Off function is certified and the related safety circuit will allow the HDS03.2-W075N-HT25-01-FW to reach the following certifications: PL d CAT 3 (EN 13849-1) and SIL 2. The HDS03.2-W075N-HT25-01-FW can be shipped to any address worldwide with a one-year warranty period from Wake Industrial.

HDS03.2-W075N-HT25-01-FW Documents

  • HDS032W075NHT2501FW
  • HDS03 2 W075N HT25 01 FW
  • hds03.2-w075n-ht25-01-fw

HDS03.2-W075N-HT25-01-FW Technical Specifications

Command Communication: Sercos
Controller Family: DIAX04
Cooling: Internal Blower
Rated Current: 75A
